Denon PMA-A110 User Guide

Listen to audio from PC or Mac
1. Power on.
2. Press INPUT SELECT to switch the input source to “USB-DAC”.
3. Set the audio signal destination to this unit on
4. Set the audio signal destination to this unit on the computer.
Windows OS
1. Click the “Start” button and click “Control Panel” on the PC.
The control panel setting list is displayed.
2. Click the “Sound” icon.
The sound menu window is displayed.
3. Check that there is a checkmark next to “Default Device” under in “PMA-A110” of the “Playback” tab.
When there is a checkmark for a diff erent device, click “PMA-A110” and “Set Default”.
4. Select “PMA-A110” and click “Properties”.
The PMA-A110 Properties window is displayed.

Denon PMA-A110 Specifications

General

Input Sensitivity MM	2.5 mV / 47 kOhm
Treble Control	±8 dB at 10 kHz
Bass Control	±8 dB at 100 Hz
Standby Consumption	0.2 W
Dimensions	434 x 182 x 450 mm
Total Harmonic Distortion	0.007%
Frequency Response	5 Hz - 100 kHz
Input Sensitivity MC	200 µV / 100 ohm
Power Output (8 Ohm)	80 W (20 Hz - 20 kHz, THD 0.07%)
