Denon UD-M31 Service Manual

26
26UD-M31
PARTS LIST OF P.W.B. UNIT ASS'Y
1U-3498 MAIN UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q’ty New
SEMICONDUCTORS GROUP
IC201 262 3180 208 UPD784216AGC-203-8EU
IC202 262 2986 005 93LC66
IC203 263 1093 002 BA05ST
IC205 263 0454 901 M51957BFP(TP1)
IC301 262 1875 900 BU4066BCF-T1
IC302 262 3181 906 LC75342M *
IC303 262 2547 907 LC72720NM
IC304,305 263 0615 902 BA15218F-DXE2
IC401 262 3182 002 LC75725E *
IC402 499 0301 006 RPM6938-V4
IC501 265 0109 003 STK402-050
IC601 269 0170 005 TOTX178
IC602 263 0809 006 NJM7805FA(S)
IC603 263 0801 004 NJM7812FA(S)
IC604 263 0793 002 NJM7806FA(S)
IC605 263 0809 006 NJM7805FA(S)
IC606,607 268 0073 905 ICP-N15T
TR209 269 0185 906 DTA115TKAT146
TR211 269 0083 901 DTA114EKT96
TR301 269 0066 902 DTC323TKT96
TR303,304 269 0054 901 DTC144EKT96
TR305 269 0083 901 DTA114EKT96
TR306 269 0066 902 DTC323TKT96
TR307 269 0082 902 DTC114EKT96
TR308 269 0066 902 DTC323TKT96
TR309 273 0426 907 2SC2412KLNT146
TR310 269 0083 901 DTA114EKT96
TR311,312 269 0066 902 DTC323TKT96
TR313 269 0082 902 DTC114EKT96
TR315 269 0066 902 DTC323TKT96
TR317 273 0384 900 2SC2412KT96(S)
TR401,402 269 0082 902 DTC114EKT96
TR501 271 0309 905 2SA1037AKT146S
TR502-504 273 0426 907 2SC2412KLNT146
TR601 271 0309 905 2SA1037AKT146S
TR602,603 273 0426 907 2SC2412KLNT146
TR604 269 0160 905 DTC143ZSATP
TR605 272 0025 907 2SB562(C)TF
TR606,607 273 0426 907 2SC2412KLNT146
TR611 269 0091 906 DTC143TKT96
TR612 269 0083 901 DTA114EKT96
TR613 269 0082 902 DTC114EKT96
D301-303 276 0375 905 1N4148T77 (TAPE)
D305,306 276 0375 905 1N4148T77 (TAPE)
D601 276 0375 905 1N4148T77 (TAPE)
D602,603 276 0772 003 1N4004
D604-606 276 0375 905 1N4148T77 (TAPE)
D607-610 276 0772 003 1N4004
D611 276 0741 005 D3SBA60
D612,613 276 0772 003 1N4004
