PARTS LIST OF EXPLODED VIEW
Ref. No Part No Part Name Remarks Q'ty NEW
1 1U-3498 MAIN PWB UNIT 1
1-1 POWER UNIT
1-2 AMP1 UNIT
1-3 AMP2 UNIT
1-4 DISPLAY UNIT
1-5 SPEAKER UNIT
1-7 I/O UNIT
1-8 U-CON UNIT
1-9 JUNCTION UNIT
1-6 1U-3507 CD PWB UNIT 1
2 144 2820 106 FRONT PANEL 1 *
3 146 2300 208 INNER PANEL 1 *
4 143 1161 106 WINDOW 1 *
5 113 1947 109 KNOB (L) 3P 1 *
6 113 1948 001 KNOB(S)3P 1 *
7 113 1949 000 KNOB(S)2P 1 *
8 143 1086 003 REMOCON FILTER 1
9 113 1955 007 POWER KNOB ASS'Y 1 *
10 112 0856 104 VOLUME KNOB ASS'Y 1 *
11 146 2298 006 LOADER PANEL(UD) 1 *
13 411 1940 411 MAIN CHASSIS 1 *
14 104 0317 008 FOOT 4
15 461 1066 002 FELT 4
16 417 0596 013 HEAT SINK 1 *
17 415 0908 003 SHIELD PLATE 1 *
18 412 4621 002 MECHA HOLDER 1
19 337 0100 006 CD MECHA(CD11FTA3N) 1
20 105 1425 206 REAR PLATE (UD) 1 *
21 412 4622 001 PCB SUPPORT(A) 1
22 102 0633 139 TOP COVER 1 *
! 23 233 6441 001 POWER TRANS(E2) 1 *
! 24 206 2089 106 AC CORD W/CON.E2 For E2 1
! 206 2128 009 AC CORD W/CON EK For EK
25 445 0056 008 CORD BUSH 1
26 216 0108 002 TUNER PACK (TFCE1E5) 1
27 443 9015 002 P.W. SPACER 3
28 412 2814 002 CARD SPACER (L=8) 2
29 393 8068 001 FL TUBE(HNA-11SS47T) 1
30 449 0172 007 SENSOR HOLDER 1
31 415 0844 002 PVC SHEET 1
33 414 0982 000 PARTITION SHEET 1 *
35 415 0906 102 SAFETY COVER 1 *
36 441 1976 004 SPACER 1 *
37 412 4839 001 EARTH PLATE(H/P) 1
38 441 1977 003 WASHER 1 *
40 131 0156 106 DENON BADGE 1
42 412 5014 100 TRANS BRACKET 1 *
43 412 5012 005 PCB SUPPORT BRACKET 1 *
44 445 0048 016 CORD HOLDER (L50) 2
45 009 0241 028 16P FFC CABLE CX162 1 *
46 009 0207 020 15P FFC(1.25) CY152 1 *
47 415 0911 003 SAFTY SHEET 1
143 1085 004 LENS 1
415 0585 015 UL TUBE(16) BK L=30 1
445 8004 007 WIRE CLAMPER 5
513 3673 008 LASER PICK LABEL 1
513 3857 002 E2 LASER CAUTION (E) 1
513 3632 007 CAUTION LABEL 1
Note: The symbols in the column “Remarks” indicate the following destinations.
E2: Europe model EK: U.K. model
