41
41UD-M31
PACKING VIEW
PACKING LIST OF PACKING & ACCESSORIES
Ref. No. Part No. Part Name Remarks Q’ty NEW
201 505 0038 030 POLY COVER 1
202 511 3982 007 INST MANUAL 1 *
203 515 0921 102 S.S.LIST(EX) 1
204 - BATTERY (UM-4) ASS 1
205 399 0855 003 REMOCON (RC-933) 1
206 231 0922 009 LOOP ANTENNA 1
207 395 0026 005 FM ANT. WIRE 1
208 - CONT.CARD(L) 1
209 501 2231 105 CARTON CASE 1 *
210 503 1451 005 CUSHION(L) 1 *
211 503 1452 004 CUSHION(R) 1 *
212 502 1074 007 CUSHION BOARD (A) For EK 1 *
213 517 1471 000 E2 POS LABEL For E2 1 *
517 1472 009 EK POS LABEL For EK 2 *
214 513 1642 002 NO. SHEET 1
215 505 0358 008 POLY COVER For EK 1
210
201 207~
211
208
209
212
Note: The symbols in the column “Remarks” indicate the following destinations.
E2:Europe model EK: U.K. model
To Next Page
