Denon UD-M31 Service Manual

31
31UD-M31
CX72 205 0535 086 7P CONN.BASE
CX81 205 0355 088 8P KR CON BASE(L)
CX121 205 0375 026 12P CONN.BASE(KR-PH)
CX143 205 0708 033 14P CONN.SOCKET
CX151 205 0480 050 15P KR CON BASE(L)
CX153 205 0767 058 15P CON BASE *
CX171 205 1006 080 17P FFC BASE(P=1)
CX181 205 1050 052 18P FFC BASE(SIDE) *
CX251 205 1050 010 25P FFC BASE (9603F)
CY38 205 0406 034 3P CON BASE(KR-PH)
CY41 203 6590 016 4P PH-SAN CONN CORD *
CY42 203 6592 001 4P PH-SAN CON CORD *
CY51 203 8535 011 5P VH-SAN CON CORD *
CY72 205 0536 085 7P CONN.SOCKET
CY81 204 2933 010 8P PH-SAN CON CORD *
CY121 205 0480 021 12P KR CON BASE(L)
CY143 205 0707 034 14P CONN.BASE
CY151 204 6753 005 15P PH-SAN CON CORD *
CY152 205 0736 076 15P FFC CON.BASE
CY153 205 0766 059 15P CON SOCKET *
CY171 205 1006 080 17P FFC BASE(P=1)
CY181 205 1050 052 18P FFC BASE(SIDE) *
! F601 206 1074 073 FUSE (0.5A)
! F602 206 1075 043 FUSE(2.5A)
FF601,602 202 0040 909 FUSE CLIP (TAPE)
FH601,602 202 0040 909 FUSE CLIP (TAPE)
FL401 393 8068 001 FL TUBE(HNA-11SS47T)
JK301,302 204 8635 024 4P PIN JACK (C-GND)
JK303 204 8642 004 1P P1N JACK BK
JK401 204 8636 007 MINI JACK (ST.SW)
JK408 205 1261 003 SP TERMINAL(R) *
JK601,602 204 8637 006 MINI JACK (STEREO)
! JK604 203 3961 004 1P AC OUTLET(E2)
L501,502 235 0104 010 INDUCTOR(3UH) *
RL601 214 0206 005 RELAY(PCI212DM)
RL602 214 0224 003 RELAY(0JT-SS-109LM) *
RL603 214 0203 008 RELAY(NA12W-K)
SW402,403 212 0467 000 TACT SW(H=5)
SW405-407 212 0467 000 TACT SW(H=5)
SW409-412 212 0467 000 TACT SW(H=5)
SW413 212 0461 006 ROTARY ENCODER(V)
! T601 233 6383 004 POWER TRANS(SUB/E2)
W705 203 0322 057 1P CONTACT ASS'Y
W717 203 0541 058 1P SIN CORD ASS'Y
W719 001 0026 045 WIRE CORD
X201 399 0532 902 CST12.5MTW-TF01
X301 399 0178 007 X-TAL(4.332MHZ)
125 9002 007 UL TUBE (L=10) 2
1U-3498 MAIN UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q’ty New

Denon UD-M31 Specifications

General

Brand	Denon
Model	UD-M31
Category	Car Receiver
Language	English
