DEREE DE-5000 - Electrical Specification

- 36 -
Ϯʳ Inductance (Parallel / Series mode).
Range Resolution 100/120Hz 1kHz 10kHz 100kHz
20.000ȝH 0.001ȝH ņ ņ ņ 2.5%+5*
200.00ȝH 0.01ȝH ņ ņ 1.2%+5* 0.6%+3
2000.0ȝH 0.1ȝH ņ 2.0%+5* 0.6%+3 0.6%+3
20.000mH 0.001mH 1.2%+5* 1.0%+5 0.3%+2 0.6%+3
200.00mH 0.01mH 0.3%+2 0.6%+3 0.3%+2 1.2%+5*
2000.0mH 0.1mH 0.3%+2 0.3%+2 0.6%+3 ņ
20.000H 0.001H 0.3%+2 0.6%+3 1.2%+5* ņ
200.0H 0.1H 0.6%+3 1.2%+5* ņ ņ
2.000KH 0.001KH 1.2%+5* ņ ņ ņ
ƔIf reading <2000, unit on display is ȝH
* Do open/short calibration before measuring for above ranges with * to have better precision
measurements.
Ϯʳ Accuracy v.s. Resistance (ZDUT)
DCR 100/120Hz 1kHz 10kHz 100kHz
0.1~1ȍ 1.2%+5* 1.2%+5* 1.2%+5* 1.2%+5* 2.5%+5*
1~10ȍ 0.6%+3* 0.6%+3* 0.6%+3* 0.6%+3* 1.2%+5*
10~100kȍ 0.3%+2 0.3%+2 0.3%+2 0.3%+2 0.6%+3
100k~1Mȍ 0.6%+3 0.6%+3 0.6%+3 0.6%+3
1M~20Mȍ 1.2%+5* 1.2%+5* 1.2%+5* 2.5%+5*
2.5%+5*
100k~2Mȍ
>20Mȍ 2.5%+5* 2.5%+5* 2.5%+5* ņ ņ
*
Do open/short calibration before measuring for above ranges with * to have better precision
measurements.
If D > 0.1, the accuracy should be multiplied by
2
D1
If D << 0.1 in capacitance mode ZC = 1/2ʌfC
If D << 0.1 in inductance mode ZL = 2ʌfL
Sub-display parameters accuracy
Ae = impedance (Z) accuracy
Definition: Q = 1/D & Rp = ESR * (1+1/D2)
D value accuracy De =
ʳ 
Ae *(1+D)
ESR accuracy Re=

ZM * Ae (ȍ)
ie., ZM = impedance calculated by 1/2ʌf C or 2ʌf L
Phase angle ș accuracy șe=

(180/ʌ) * Ae (deg)
Appearance and specification may be revised if needed
without prior notice.
DER EE is assessed and certificated as meeting the
requirements of ISO 9001:2000. We produce meters in
various types and specification and all our product
conforms to ISO standards. If any further inquiry needed,
please visit our website at www.deree.com.tw
HCA500000-00020
