6.3.12. REPORTING NUMBER OF ENROLLED CONTROLLERS VIA BUZZER SOUND
Your motorized cylinder can report number of enrolled controllers via buzzer sound. To do this, follows the steps below:
- Touch to device with your palm to wake it up. Two arrows will appear on display. Touch “Button #2”. ADMIN will be shown.
- Put one of the master fingers onto the reader. First “OK” and then “LEARN” will be shown.
- Touch “Button #2" till “R.COUNT” appears and touch “Button #1" when “R.COUNT” is on display.
- “OK” will be displayed.
In this way, motorized cylinder will start to report number of enrolled controllers via short warning tones.
Schematic representation of operation is as follows:
DESi
OK
OK
ADMIN R.COUNT
