#Pizza Hut Make Table operating and service manual
21
3) EVAPORATOR FAN TURN ON
As soon as evaporator coil reaches a proper temperature, the evaporator fans will cut-in.
CIRCUIT B
PAN COOLER
CIRCUIT A
COUNTER
FAN LED
