Desoutter ERS6 - Product Data; ERS Series Data; ERS-M20 Series Data

10/20194 / 72
6159933670
Issue no: 14
DATA
ERS
ERS-M20
Model Part number Output
Torque (Nm) Torque (in.lbs)
Speed
(rpm)
130%
Weight
Min Max Min Max kg lb
ERS2 6151656880 Hex 1/4" 0.6 2.5 5.3 22.1 3000 0.7 1.54
ERS6 6151656890 Hex 1/4" 1.0 6 8.8 53.1 1725 0.7 1.54
ERS12 6151656900 Hex 1/4" 1.5 12 13.3 106.2 950 0.7 1.54
Model Part number Output
Torque (Nm) Torque (in.lbs)
Speed
(rpm)
130%
Weight
Min Max Min Max kg lb
ERS2-M20 6151656910 Hex 1/4" 0.6 2.5 5.3 22.1 3000 0.7 1.54
ERS6-M20 6151656920 Hex 1/4" 1.0 6 8.8 53.1 1725 0.7 1.54
ERS12-M20 6151656930 Hex 1/4" 1.5 12 13.3 106.2 950 0.7 1.54
Ø40.4
(1.6)
Ø36 (1.4)
50.6 (2)
209 (8.2) 38.5
(1.5)
299 (11.7)
4000
(157.4)
Dimensions : mm (in)
20
(0.8)
Dimensions : mm (in)
Ø40.4
(1.6)
Ø36 (1.4)
50.6 (2)
209 (8.2)
38.5
(1.5)
299 (11.7)
4000
(157.4)
