Desoutter ERS6 - ERS22-M20 Series Data; ERSA Series Data

10/2019 5 / 72
6159933670
Issue no: 14
DATA
ERS22-M20
Model Part number Output
Torque (Nm) Torque (in.lbs)
Speed
(rpm)
130%
Weight
Min Max Min Max kg lb
ERS22-M20 6151659160 Square 3/8” 6 22 53.1 194.7 380 1.05 2.31
The output HEX 1/4" can be ordered as spare part (part number: 2050538593).
Ø36 (1.4)
50 (2.0)
Ø39 (1.5) Ø40 (1.6)
Square 3/8"
248 (9.8)
14.2 (0.5)
24 (0.9)
38.5
(1.5)
4000
(157.4)
Dimensions : mm (in)
337 (13.3)
Model Part number Output
Torque (Nm) Torque (in.lbs)
Speed
(rpm)
130%
Weight
Min Max Min Max kg lb
ERSA2 6151656970 Hex 1/4" 0.6 2.5 5.3 22.1 2500 1.0 2.2
ERSA6 6151656980 Hex 1/4" 1.0 6 8.8 53.1 1450 1.0 2.2
ERSA12 6151656990 Hex 1/4" 2.0 12 17.7 106.2 800 1.0 2.2
ERSA
40.7 (1.6)
6.2 (0.25)
Ø36 (1.4)
50.6 (2)
245 (9.6) 38.5
(1.5)
346 (13.6)
4000
(157.4)
Ø40.4 (1.6)
Dimensions : mm (in)
