Desoutter ERS6 - Clamping Accessories and Positions; Clamping Area Guidance

10/20198 / 72
6159933670
Issue no: 14
FASTENING AND CLAMPING REQUIREMENTS
B
B1
Part number Designation Clamping position
6158101270 Holder dia 36.5 (12 - 25 N.m) 2
6158101180 TRA Uniholder (12 - 25 N.m) 2 / 3
6158108350 Tool Clamp dia 28.5 - 41 2 / 3
61581011806158101270 6158108350
3
2
Preferable
clamping
area
Possible
clamping
area
Do not clamp the tool
on this area
