Deutronic DBL Manual (MPC4) - 14VDC - EN - 14 / 20 - 10 / 2006
Parameter Value Setting range / Information
DISPLAY:
SLEEPMODE ON / OFF
Activate / deactivate display sleep mode.
After about 1 min of no user action on the DBL the display goes into sleep
mode (see picture below).
Note: Useful if operation state should only be signalized by the signal
LEDs or an external control unit / signal lamp.
SIGNAL 0
1
2
Preset individual signalization modes for LEDs 1-3 and external signal
lamp - see also 8) Annex – Indication / LED and Signal Lamp
KEY LOCK ON / OFF
Activate / deactivate PIN code to limit access to the user menu
CODE 0000 .. 9999
Preset PIN code (e.g. 0005), user selectable
Parameter Value Setting range / Information
VERSION:
Displays version information and charger SERIAL NR.
Example for DBL800:
