Control parts
TCD 2013 2VW 11-02-01
Technical Data
Tightening specifications
ID no. Name Screw type Notes / Remark Value
A01 002
Rocker arm support on the cylinder
head
Assembly note:
Rocker arm symmetrical
to the valve centre axes.
30 Nm
For the tightening procedure according to torque using a torque wrench, a maximum variation of the
tightening torque of +/- 10% is permissible.
