High-pressure pump
TCD 2013 2VW 17-01-05
Technical Data
Tightening specifications
ID no. Name Screw type Notes / Remark Value
A07 003
Injection pipe on rail and injector,
High pressure pipe on high pressure
pump and rail
Union nut
Stage 1:
Observe assembly
specification.
Use new pipe.
10 Nm
A07 003
Injection pipe on rail and injector,
High pressure pipe on high pressure
pump and rail
Union nut Stage 2:
60°
A07 031 High pressure pump to crankcase M10x30-10.9
Stage 1:
Screws oiled
10 Nm
A07 031 High pressure pump to crankcase M10x30-10.9 Stage 2: 50 Nm
A12 092
Pipe union, pipe diameter 8 mm, ring
piece
Hollow screw
M12x1.5
29 Nm
A12 093
Pipe union, pipe diameter 10 mm, ring
piece
Hollow screw
M14x1.5
39 Nm
For the tightening procedure according to torque using a torque wrench, a maximum variation of the
tightening torque of +/- 10% is permissible.
