© 02/2010 OBJ_DOKU-21749-001.fm
1/4
6
Crankcase
TCD 2013 2V W 01-07-03
Removing and installing the pressure holding valve
Standard tools
Special tools:
– Slide hammer 150800
– Locking agent
DEUTZ DW 71
– W 16-01-01
Collect leaking operating substances in
suitable vessels and dispose of according
to regulations.
Removing the pressure holding valve
● Remove oil suction pipe
W 16-01-01
● Pull out oil dipstick.
● Drill out hole with a 6.7 mm Ø drill.
Make sure no chips get into the crankcase.
Coat spiral drill thickly with grease, so that
no drill shavings fall into the crankcase.
● Cut thread M8 x 1.25.
