Cylinder liner
TCD 2013 2VW 04-01-01
● Fold the plate (1) to the side and insert the disassem
-
bly device in the cylinder liner.
Attention!
Do not damage the running surfaces and
the sealing surfaces.
● Mount the counter holder (1) on the crankcase.
Do not mount the counter holders on the
cylinder liner's sealing surface.
● Place the plate (1) with the lay-on surfaces against
the cylinder liner (2) and hold them together.
