1.1 Technical Specifications
Operation voltage 220-240V~, 50Hz
Standby power consumption Max 0.25W
Relay:
Resistive load
Inductive load
Max 16A / 3680W @ 230V
cos φ= 0.3 max1A
Sensing units NTC 15kOhm at 25°C
Sensing values:
0°C
25°C
50°C
42kOhm
15kOhm
6kOhm
Hysteresis ± 0.2°C
Ambient temperature 10°C to +50°C
Lowering in economy periods -5°C
Temperature range +5 to +45°C
Cable specification max
1x4mm
2
or 2x2,5mm
2
Ball pressure temperature 75°C
Pollution degree 2 (domestic use)
Type 1C
Storage temperature -20°C to +65°C
IP class 20
DEVIreg™ 330 (+5 to +45°C)
4 Installation Guide
