Deviate Claymore User Manual v1.8 12.12.23Deviate Claymore User Manual v1.8 12.12.23
BOTTOM BRACKET WASHER
Provided in the box is a BB washer (part number 14 on Front Triangle Assembly). Please
ensure this is fitted when installing the BB between the frame and BB. It replaces the 2.5mm
spacer found with BB’s to achieve a 52mm chainline. Additional spacers may be required for
certain BB’s.
MAINTENANCE
SERVICE INTERVALS
Action Every Ride 50hrs Notes
Clean/Lube Train • Not wax chain lubricants
Check Tyre Pressures •
Clean Mud/Debris •
Check Brake Function •
Clean Stanchions •
Check Brake Pad Wear •
Check Shock Pressure • See manufacturer guidelines (25-30% sag)
Check For Loose Bolts •
Lube Grease Ports • See diagrams for port locations
(Pages 10, 12)
Check Tyre Wear •
Check Spoke Tension •
Check Drivetrain Wear • Replace chain before 0.75% wear
Check Bearing Wear • Check for play in pivots and idler
Rebuild Linkages As Required
Fork Service Refer to fork manufacturers
recommendations
Shock Service Refer to shock manufacturers
recommendations
GREASE PORTS
After locating the grease ports (see diagrams on pages 10 & 12) use a Deviate Cycles Dualco
grease gun to insert Peaty’s speed grease into the specified port. Ensure any excess grease is
cleaned and removed prior to using the bike.
PARTS LIST
QUICK REFERENCE SPARES
The following table is a quick reference for typical spares you might need over the life of the bike:
Part Part Number Quantity Per Frame
Dropout TRP04-D9-008-C 1
Rear Axle TRP04-S9-022-A 1
Idler TRP04-D9-006-D 1
Idler Bearings 61803_2RS1 2
Main Pivot, Rear Links, Extender Bearing 3802 LLU MAX 7
Rocker Bearing 6808 LLU MAX 2
Idler Seals, Main Pivot Seals SEAL - 20x26x4 VC 10
Rear Triangle Inner Seal SEAL - 16x22x4 VC 2
Cable Grommet (Large) G10 RCS60-00-45 2
Cable Grommet (Small) G10 RCS50-00-35 3
Deviate Cycles can happily supply any spares
that you may need for your bike, but some
items such as bearings and seals can be
sourced from you local bearing dealer.
For all other frame related spares please
contact us or check the online store. The use
of non-genuine parts is not recommended
and would void the warranty associated with
Deviate products.
BOLT TORQUE SUMMARY
Part Torque (Nm)
Main Pivot Bolt 30
Pull Link to Rocker Bolt 30
Pull Link to Rear Triangle Bolt 20
Shock Extender to Rocker Bolt 20
Sleeve - Shock 20
Sleeve - Frame Bolt 10
Rear Axle 10
Idler Cover Bolts 2
Drop Out Bolts 2
Bottle Cage Bolts 3
If a bolt is found to
be loose it should be
removed and the relevant
thread locktite should be
applied as detailed in
the product diagrams on
pages 8, 10, 12.
