Page 2 SB-2-586-E
Operation Manual
Compact-I Automatic Spraygun
Important
Read and follow all instructions and Safety Precautions before using
this equipment
CHARACTERISTICS
This automatic spray gun complies to ATEX regulations
94/9/EC, protection level II 2 G X, suitable to use in Zones
1 & 2.
This Compact-I is a production spray gun suitable for
use with automatic and semi-automatic machine in
conventional, HVLP or Trans-Tech application. (See page
9 for application details.)
To handle a wide range of coating materials the material
passages are manufactured from high grade stainless
steel. Several needles are available with plastic tips.
Fluid tips and needles are available in high grade stainless
steel.
Pressure feed material supply can be re-circulating or
direct.
The needle adjustment knob has 18 ratchet positions
(per one revolution of the knob) which allows fine and
accurate fluid flow control.
SPECIFICATIONS & MATERIALS OF CONSTRUCTION
Thread Pressure
Fluid inlet & recirculation “P” & "R"
1/4" BSPP(F) Max 7 Bars (100 psi)
Air inlet (Atom & Fan) “A” & “F”
1/4" BSPP(F) Max 7 Bars (100 psi)
Cylinder/trigger “Cyl”
1/8" BSPP(F) 4 to 7 Bars (60-100 psi)
Maximum temperature in use
40° C (104° F)
Spray gun weight
656 gms (1.44 lbs)
Gun body
Aluminium hard anodized
Tip / Needle / Spray head
Stainless steel 303
EC Declaration of Conformity
We, ITW Finishing UK, Ringwood Rd, Bournemouth, Dorset, BH11 9LH, UK, as the manufacturer of the
Spray gun model Compact-I, declare, under our sole responsibility that the equipment to which this
document relates is in conformity with the following standards or other normative documents:
BS EN 292-1 PARTS 1 & 2: 1991, BS EN 1953: 1999; and thereby conform to the protection requirements
of Council Directive 98/37/EEC relating to Machinery Safety Directive, and; EN 13463-1:2001, council
Directive 94/9/EC relating to Equipment and Protective Systems intended for use in Potentially
Explosive Atmospheres protection level II 2 G X.
B. Holt, General Manager
24th April 2007
ITW Industrial Finishing reserves the right to modify equipment specification without prior notice.
CA PROP
65
PROP 65 WARNING
WARNING: This product
contains chemicals known
to the State of California
to cause cancer and birth
defects or other
reproductive harm.
