PARTS LIST
Item Description
Order
Part Number
Qty
1 Air cap and its retaining ring with seals. See chart on page 6. SP-100-xxx-K 1
2
Tip with air separator seal
Ø 0.85 / 1.0 / 1.4 / 1.8 / 2.2 mm
Ø 0.5 for air cap 590
Air cap 591
SP-200S-xx-K
SP-259S-xx-K
1
4 Locator ring for indexed air cap SPA-112 1
5 Air separator ring (kit of 5 rings) SPA-27-K5* 1
6 Screw M4 x 25 (kit of 4 Torx 20 screws) S-14192-K4* 4
8 Spray head for Compact-I SPA-40 1
9 Packing seal (kit includes items 9

, 10, 11, 16a) SPK-115* 1
10 Sealing washer (kit includes items 9, 10, 11, 16a) SPK-115* 1
11
O-ring gasket (kit includes items 9, 10, 11
n
, 16a)
SPK-115* 2
12 Gun body for Compact-I SPA-1-CMAI-S 1
13 Air valve (fan and atomizing air) AGG-403 2
14 O-ring (kit includes items 14, 15a, 16) SPK-104* 1
15 Piston + o-ring (kit includes items 14, 15a, 15b, 16) SPA-6X-K* 1
15a O-ring (kit includes items 14, 15a, 16) SPK-104* 1
15b Piston REF. 1
16 O-ring (kit includes items 14, 15a, 16) SPK-104* 1
16a O-ring (kit includes items 9, 10, 11, 16a) SPK-115* 1
17 Piston Spring (kit includes items 17, 22, 23, 24) SPK-105* 1
18
Stainless steel needle 0.5 / 0.85 / 1.0 / 1.4 / 1.8 / 2.2 mm
Plastic tip needle 0.85 / 1.4 mm
SPA-310-xx
SPA-310P-xx
1
19 Housing SPA-3 1
20 Kit of ring and ball for ratchet (kit includes items 20, 21, 25) SPK-106* 1
21 Ring (kit includes items 20, 21, 25) SPK-106* 1
22 Needle spring (kit includes items 17, 22, 23, 24) SPK-105* 1
23 Spring cap (kit includes items 17, 22, 23, 24) SPK-105* 1
24 Spring washer (kit includes items 17, 22, 23, 24) SPK-105* 1
25 Adjusting knob (kit includes items 20, 21, 25) SPK-106* 1
27 Kit for air connection of remote control (includes "A" and "F" fittings) SPA-22-K2* 1
28 Gun mounting bar (kit includes items 28, 29, 31) SPK-110* 1
29 Gun mounting bar nut (kit includes items 28, 29, 31) SPK-110* 1
30 Plug ¼" BSPP for spray gun without fluid recirculation REF. 1
31 M5 hexagon socket head cap screw, length 8 (kit includes items 28, 29, 31) SPK-110* 2
32 Fluid insert plug REF. 1
33 Kit of retaining ring with gasket (kit includes air cap ring and gaskets) SPK-102-K* 1
*
Spare parts must be ordered as part of replacement kits listed above.

Item 9: Fluid packings only (10 pack) SPA-86-K10.
n Item 11: Air gaskets only (10 pack) SPA-53-K10.
See page 10 for additional adapter/fitting kits for air and fluid hoses.
For the arrangement of the parts, refer to the exploded view on page 5.
