DeVilbiss GFG PRO - Kit Contents; Construction Features; Materials of Construction; Specifications & Technical Data

4 © 2012 Finishing Brands UK Ltd.
Kit contents
1
GFG PRO Gravity Feed Spraygun
1
Spanner (10mm and 14mm A/F)
1
GFC Gravity feed cup
1
Torx/Flat blade screwdriver
1
Cup Filter
1
Cleaning Brush
1
Set of 4 coloured identification rings
1
Service bulletin
Construction Features
1
Air Cap (nickel plated brass for long durability)
10
Fan Air Adjustment (stepless regulation for fan to
round spray)
2
Air Cap Retaining Ring (allows easy rotation of air cap)
11
Fluid Adjustment (stepless regulation of fluid
volume)
3
Fluid Nozzle (ideal for automotive topcoat systems)
12
Removable Spray Head (for long gun service life)
4
Fluid Needle (grooved stem for easy removal)
13
Interchangeable Colour ID System (4 coloured
rings supplied)
5
Fluid Inlet (3/8 BSP thread – accepts DeVilbiss and
most other cup systems)
14
Anodised, forged aluminium gun body
(ergonomic, good looking & durable, easy to
clean)
6
Air Inlet (universal thread, accepts G 1/4 & 1/4 NPS)
15
500cc Acetal Cup (easy clean, anti-static)
7
Self Adjusting Needle Packing (for trouble free
operation)
16
Cup Lid with Drip Free Vent (avoid drips)
8
Trigger (ergonomic for comfort)
17
Air Valve (design offers low pull force & low
pressure drop)
9
Trigger Stud & Screw (easy replacement design)
18
Gun acceptable for waterborne and solvent
borne applications
Materials of Construction
Gun Body
Anodised aluminium
Air Cap,
Nickel plated brass
Fluid Nozzle, Fluid Needle, Fluid Inlet, Trigger Stud
Stainless steel
Spray Head
Anodized aluminium
Springs, Clips, Screws
Stainless steel
Seals, Gaskets
Solvent resistant
Trigger
Chrome plated steel
Air Inlet, Body Bushing, Spreader Valve Body, Air Valve Nut, Air
Cap Retaining Ring, Knobs
Chrome plated brass
Air Valve Assembly
Stainless Steel, HPDE
Specifications & Technical Data
Air Supply Connection
Universal 1/4" BSP and 1/4" NPS male
Maximum Static Air Inlet Pressure
P1 = 12 bar (175 psi)
Gun Air Inlet Pressure all caps with gun triggered.
See chart 1, p13
Fluid Supply Connection
3/8" BSP
Service Temperature
0 to 40°C (32 to 104°F)
Gun Weight (gun only)
(with cup)
585g
768g
