PARTS LIST
REF.
NO.
DESCRIPTION
PART NO.
QTY
REF.
NO.
DESCRIPTION
PART NO.
QTY
1
Air Cap Retaining Ring
-
1
31
Air Valve Cage
-
1
2
Slip Ring
-
1
32
Air Valve Poppet
-
1
3
Air Cap
-
1
33
Air Valve Spring
-
1
4
Air Cap Retaining Clip
JGA-156-K5
1
34
Air Valve Spring Pad
-
1
5
Retaining Ring Seal
-
1
35
Air Valve Seal
-
1
6
C1 Aircap & Ring
PROC-120-C1-K
1
36
Air Valve Assembly
SN-402-K
1
C2 Aircap & Ring
PROC-120-C2-K
1
*37
Trigger Stud Screw
(T20 TORX)
-
1
38
Trigger
-
1
7
Air Cap Retaining Ring &
Seals
PRO-405-K
1
*39
Trigger Stud
-
1
8
Fluid Nozzle
See chart 2 p13
1
40
Trigger, Stud &
Screw Kit
SN-21-K
1
9
Spray Head
-
1
41
Plug
-
1
*10
Spray Head Seal (kit of 2)
SN-18-1-K2
1
42
Air Inlet
SN-40-K
1
11
Spray Head & Seal Kit
SN-17-1-K
1
43
Colour ID Ring Kit (4
Colours)
SN-26-K4
1
*12
Body Bushing Seal
-
1
44
Airflow Valve
PRO-411-K
1
13
Body Bushing
-
1
45
Circlip
25746-007-K5
1
14
Body Bushing & Seal
SN-6-K
1
46
Valve Head
-
1
15
Fluid Needle
GFGPRO-320-K
1
47
Washer
-
1
*16
Needle Spring
-
1
48
Valve Body
-
1
*17
Needle Spring Pad
-
1
49
Valve Stem
-
1
18
Fluid Adjusting Knob
-
1
50
Baffle plate
SN-41-K
1
19
Fluid Adjusting Knob,
Spring & Pad Kit
& Pad Kit
PRO-3-K
1
51
Gravity Cup Kit
GFC-501
1
*20
Retaining Clip
-
2
52
Drip Check Lid (kit of
5)
GFC-2-K5
1
21
Spreader Valve Body
-
1
53
Gravity Cup Lid
GFC-402
1
*22
Spreader Valve Seal
-
2
54
Gravity Cup
-
1
23
Spreader Valve Adjusting
Knob
-
1
55
Filter
KGP-5-K5
1
*24
Spreader Valve Pin
-
2
56
Air valve Service
Tool
-
1
25
Spreader Valve Assembly
PRO-402-K
1
57
Torx Key
SPN-8-K2
1
*26
Needle Packing
-
1
58
Stud and Screw kit
SN-405-K5
1
*27
Packing Spring
-
1
SERVICE PARTS
28
Packing Nut
-
1
Spray Gun repair kit (includes
items marked *)
PRO-415-1
29
Packing, Spring &
Packing Nut Kit
SN-404-K
1
Seal and Pin Kit, kit of 5
(items 20, 22 and 24)
GTI-428-K5
30
Air Valve Body
-
For accessories, see page 16
