DeVilbiss GTI PRO LITE - PARTS LIST

6
PARTS LIST
REF.
NO.
DESCRIPTION PART NO. QTY
REF.
NO.
DESCRIPTION PART NO. QTY
1 Air Cap Retaining Ring - 1 31 Air Inlet - 1
2 Slip Ring - 1 32
Colour ID Ring Kit
(4Colours)
SN-26-K4 1
3 Air Cap - 1 33 Air Inlet Kit SN-9-K 1
4 Air Cap Retaining Clip JGA-156-K5 1 34 Needle Packing
-
1
5 Retaining Ring Seal - 1 35 Packing Spring
-
1
6 Aircap & Ring
See chart 1
p13
36 Packing Nut - 1
7
Air Cap Retaining Ring
& Seal
PRO-420-K 1 *37
Packing, Spring and
Packing Nut Kit
SN-404-K 1
8 Fluid Nozzle Kit
See chart 2
p13
1 *38 Trigger Screw - 1
9 Spray Head - 1 39 Trigger - 1
*10 Spray head Seal SN-18-1-K2 1 *40 Trigger Stud - 1
11 Spray head kit SN-69-K 1 41
Trigger Stud & Screw
Kit
SP617-CR-K 1
*12 Circlip - 1 42 Airflow Valve PRO-407-K 1
13 Valve Body - 1 43 Circlip - Kit of 5 25746-007-K5 1
*14 O Ring - 1 44 Valve Head - 1
*15 Spreader Valve Pin - 2 45 Washer - 1
16
Spreader Valve
Adjusting Knob
- 1 46 Valve Body - 1
17
Spreader Valve
Assembly
PRO-406-K 1 47 Valve Adjusting Knob - 1
18 Front Valve Seal - 2 48 Filter KGP-5-K5 1
19 Valve Seat - 1 49 Gravity Cup - 1
20 Spindle - 1 50 Gravity Cup Lid GFC-402 1
21 Air Valve Spring - 1 51 Drip Check Lid (kit of 5) GFC-2-K5 1
22 Rear Valve Seal - 1 52 Gravity Cup Kit GFC-501 1
23 Air Valve Kit PRO-471 1 *53 Air Valve Service Tool - 1
24 Fluid Needle PRO-301-K 1 54 Tool kit SN-406 1
25 Needle Spring - 1
SERVICE PARTS
26 Spring Pad - 1
Spray Gun repair kit (includes
items marked *)
PRO-470
27 Housing SN-66-K 1
28 Fluid Adjusting Knob SN-67-C-K 1
Seal and Pin Kit, kit of 5
(items 12, 14 and 15)
GTI-428-K5
*29 Needle Spring Kit PRO-472-K3 1
30 Gunbody - 1 * Not included in the Gun Kit, only with ref 23
