STARTING
Prior to starting, refer to your engine manual for proper starting procedures
for your engine type.
1. In a well ventilated outdoor area add fresh, high quality, unleaded gasoline
with a pump octane rating of 86 or higher. Do not overfill. Wipe up spilled
fuel before starting the engine. Refer to Engine Owners Manual for correct
procedure.
2. Check engine oil level. See Engine Owners Manual
for correct procedure.
IMPORTANT: Always fill oil to the top of oil fill hole.
NOTE: There will be a slight amount of oil in the
engine from factory testing.
3. Verify the filter screen is in water inlet of pump.
NOTE: Cone side faces out.
4. Connect water source to pump inlet.
NOTE: Water source must provide a minimum of 5
gallons per minute at 20 p.s.i.
5. Connect high pressure hose to pump outlet.
6. If applying a chemical or cleaning solution, see
How To Siphon Chemicals/Cleaning Solvents in
Operation section of this manual.
7. Turn water source on. NOTE: Make sure water
supply is turned on.
8. Start engine. See Engine Owners Manual for
correct procedure. NOTE: If the engine does not
start after two pulls, pull the trigger to relieve the
pressure.
9. Depress trigger on gun to start water flow.
NOTE: Stand on a stable surface and grip
gun/wand firmly with both hands. Expect the gun
to kick when triggered.
10. Release trigger to stop water flow.
11. Adjust nozzle spray for the task being performed or change quick connect
tip. See How To Use Wand instructions in this section.
SHUTTING DOWN
1. After each use, if you have applied chemicals, place chemical hose into
container of clean water and draw clean water through chemical injection system
to rinse system thoroughly. NOTE: Failure to do so could cause damage to the
pump.
2. Turn engine off. See Engine Owner’s Manual. NOTE: NEVER turn the water
off with the engine running.
3. Turn water source off.
4. Pull trigger on spray gun to relieve any water pressure in hose or spray gun.
5. See Storage section in this manual for proper storage procedures.
Filter Screen
Water
Source
High Pressure
Hose Hook-up
Correct
oil level
to top of
oil fill
hole
Oil
