10
monitor function is active, you can listen to the
sound of channel 8 through the speaker.
Example 3
：
Test the RF level and the sound on 106.80MHz
1. Access the LEVEL mode by pressing CH/F ke y.
2. Press CH/F again to toggle in frequency test
mode.
3. Press
or to adjust the 10KHz bit as 0.
4. Press
or to adjust the 100KHz bit as 8,
then it shows XXX.8MHz.
5. Press
till the 1MHz bit blinks, adjust the
frequency to XX6.8 MHz.
6. Press
till the 10MHz bit blinks, adjust the
frequency to X06.8MHz.
7. Press till the 100MHz bit blinks, adjust the
frequency to 106.8MHz.
8.
The level is tested and shown on the right of the
screen, meanwhile the sound monitor function
automatically starts, the built-in speaker plays the
sound of the current frequency.
