Devolo dLAN 1200+ User Manual

Introduction 12
devolo dLAN 1200+
2.1 What exactly is dLAN?
dLAN (direct Local Area Network) uses the house-
hold power grid to transfer data between comput-
ers equipped with suitable adapters and other
network components. As a result, any power outlet
can be used as a network access point. The data is
modulated prior to transfer and sent as a signal via
household power lines. State-of-the-art technolo-
gy ensures that the power and data networks do
not interfere with one another. Networking via
dLAN is fast and secure. The data is encrypted us-
ing a key to prevent interception by third parties.
2.2 The dLAN 1200+
b Your home network from the power socket.
Unpack. Plug it in. Get started. The easy way to
connect using your home's power lines. Turn
any power socket into an Internet access point
b The fast transfer rate and dLAN speeds up to
1200 Mbps allow you to experience entertain-
ment at the highest level. The range+ techno-
logy provides an even more stable Internet
connection with significantly longer range.
b The automatic data prioritisation ("Quality of
Service") ensures interference-free reproduc-
tion of voice and video data.
b The integrated electrical socket enables addi-
tional terminal devices or multiple sockets to
be connected to the adapter just as a normal
wall socket—no power supply is lost.
b The Gigabit LAN port allows you to connect an
Internet-compatible device (e.g. a game con-
sole, television or media receiver) to the Inter-
net at any time via network cable.
b Easy data encryption at the touch of a button
or via devolo Cockpit.
b Minimal energy consumption with devolo's
innovative PowerSave technology
b Compatible with all devolo dLAN adapters
(200 Mbps, 500 Mbps, 600 Mbps and
1200 Mbps).
b Long range of up to 300 m between the adapt-
ers and reliable network speed for setting up a
home network.

Devolo dLAN 1200+ Specifications

General

Wi-Fi	No
Modulation	1024-QAM, 256-QAM, 4096-QAM, 64-QAM, BPSK, OFDM, QPSK
Power plug	-
Ethernet LAN	Yes
Damping filter	2 - 68 MHz
Security algorithms	128-bit AES
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Filter characteristics	-22 - -45 dB
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Maximum data transfer rate	1200 Mbit/s
Maximum operating distance	400 m
Ethernet LAN interface type	Gigabit Ethernet
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Certification	CE Class B
Product color	White
Current	13 A
AC input voltage	196-250 V
AC input frequency	50 Hz
Power consumption (standby)	0.7 W
Power consumption (typical)	3 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	42 mm
Width	66 mm
Height	130 mm
Package depth	190 mm
Package width	115 mm
Package height	81 mm
Package weight	380 g
