17 Installation
devolo dLAN 1200+
Additional network devices that are
connected via a multiple socket are
connected to the mains power supply by
plugging the multiple socket into the inte-
grated electrical socket of the dLAN 1200+.
3 Once you have connected at least two dLAN
adapters as described above, your
dLAN network has been set up. To secure your
dLAN network, continue with the configura-
tion as described in chapter 4 dLAN network.
3.5 Installation of devolo soft-
ware
Installing devolo Cockpit software
devolo Cockpit finds all accessible dLAN adapters
in your dLAN network, displays information about
these devices and encrypts your dLAN network in-
dividually. You can use the software to navigate to
the integrated web interface.
Operating systems supported by devolo Cockpit
(Version 5.0 or later):
b from Windows 7 (32-bit/64-bit) or later,
b from Ubuntu 13.10 (32-bit/64-bit),
b from Mac (OS X 10.9)
You can find the product manual, software
and additional information on
devolo Cockpit online at
www.devolo.global/devolo-cockpit
.
Downloading the devolo Home Network App
The devolo Home Network App is devolo's free
app also for checking and configuring WiFi, PLC
and LAN connections for the dLAN adapter (using
a smartphone or tablet). The smartphone or tablet
connects to the dLAN adapter at home over Wi-Fi.
1 Download the devolo Home Network App to
your smartphone or tablet computer from the
corresponding store.
2 The devolo Home Network App is placed in
your smartphone's or tablet's app list as usual.
Tapping on the devolo Home Network App
icon brings you to the start menu.
You can find more information about the
devolo Home Network App online at
www.devolo.global/home-network-app
.

Devolo dLAN 1200+ Specifications

General

Wi-Fi	No
Modulation	1024-QAM, 256-QAM, 4096-QAM, 64-QAM, BPSK, OFDM, QPSK
Power plug	-
Ethernet LAN	Yes
Damping filter	2 - 68 MHz
Security algorithms	128-bit AES
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Filter characteristics	-22 - -45 dB
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Maximum data transfer rate	1200 Mbit/s
Maximum operating distance	400 m
Ethernet LAN interface type	Gigabit Ethernet
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Certification	CE Class B
Product color	White
Current	13 A
AC input voltage	196-250 V
AC input frequency	50 Hz
Power consumption (standby)	0.7 W
Power consumption (typical)	3 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	42 mm
Width	66 mm
Height	130 mm
Package depth	190 mm
Package width	115 mm
Package height	81 mm
Package weight	380 g
