All about the network 21
devolo dLAN 500 AVpro UNI
In this example (see Fig. 8), the telephone wiring with-
in a building is used to establish the dLAN network for
multiple apartments in a building.
Since there is no telephone jack in apartment No. 5,
the dLAN connection is made here via the power line,
and done so using a repeater consisting of two dLAN
500 AVpro UNI units connected to the telephone jack
in apartment No. 4 via Ethernet.
Fig. 8: dLAN networking via telephone wiring and mains supply
