22 All about the network
devolo dLAN 500 AVpro UNI
In this example (see Fig. 9), various terminal devices of
an office reach the local Internet connection by means
of dLAN via the telephone wiring within the building.
Fig. 9: Office connection via dLAN using the local telephone wiring
