ENGLISH
3
An estimation of the level of exposure to vibration should
also take into account the times when the tool is switched
off or when it is running but not actually doing the job.
This may significantly reduce the exposure level over the
total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool
and the accessories, keep the hands warm, organisation
of workpatterns.
EC-Declaration of Conformity
Machinery Directive
Heavy-Duty Rotary Hammer
D25481
declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN60745-1:2009+A11:2010, EN60745-2-6:2010.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact
at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of
.
Markus Rompel
Director Engineering
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
06.02.2016
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
Technical Data
D25481
Voltage V
AC
230
(U.K & Ireland only) V
AC
230/115
Type 1
Frequency Hz 50
Power Input W 1050
No-load speed min
-1
540
No-load beats per minute bpm 3150
Single impact energy (EPTA 05/2009) J 6.1
Optimum drilling range into concrete mm 16-30
Maximum core drilling range in concrete mm 45-100
Maximum drilling range in concrete mm 40
Tool Holder SDS MAX
Collar diameter mm 76
Weight kg 5.9
Noise and vibration total values (triax vector sum) according to EN60745-2-6:
L
PA
(emission sound pressure level)
dB(A) 96
L
WA
(sound power level)
dB(A) 107
K
(uncertainty for the given sound level)
dB(A) 3
Drilling into concrete
Vibration emission value a
h, HD
= m/s² 9.4
Uncertainty K = m/s² 1.5
Chiselling
Vibration emission value a
h
,
Cheq
= m/s² 8.4
Uncertainty K = m/s² 1.5
Drilling into metal
Vibration emission value a
h
,
D
= m/s² <2,5
Uncertainty K = m/s² 1.5
The vibration emission level given in this information sheet has
been measured in accordance with a standardised test given in
EN60745 and may be used to compare one tool with another. It
may be used for a preliminary assessment ofexposure.
WARNING: The declared vibration emission level
represents the main applications of the tool. However if
the tool is used for different applications, with different
accessories or poorly maintained, the vibration emission
may differ. This may significantly increase the exposure
level over the total workingperiod.
English (original instructions)
HEAVY-DUTY ROTARY HAMMER
D25481
Congratulations!
You have chosen a
tool. Years of experience, thorough product development and innovation make
one of the
most reliable partners for professional power toolusers.
