DeWalt D28730 Instruction Manual

ENGLISH
1
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about this or
any
DeWALT
tool, call us toll free at:
1-800-4-
DeWALT
(1-800-433-9258).
1
Lock pin
2
Spark deflector screw
3
Spark deflector
4
Base
5
Fence
6
Vise
7
5/16" (8mm) hex key
8
Crank
9
Vise lever
10
Wheel
11
Guard
12
Spindle lock
13
Trigger switch
14
Lock-off lever
15
Fence bolts
16
Mounting holes
17
Operating handle
18
Carrying handle
Fig. A
4
5
6
7
8
10
11
12
17
9
9
16
16
16
13
15
2
3
1
14
18

DeWalt D28730 Specifications

General

Quantity per pack	1 pc(s)
