Date Code Position (Fig. A)
The date code 13 , which also includes the year of
manufacture, is printed into the housing.
Example:
2019 XX XX
Year of Manufacture
Description (Fig. A)
WARNING: Never modify the power tool or any part
of it. Damage or personal injury could result.
1
2
3
4
5
6
7
8
9
10
Intended Use
These drills/drivers/hammerdrills are designed for
professional drilling, percussion drilling and
screwdriving applications. DO nOT use under wet
conditions or in the presence of flammable liquids or
gases.
These drills/drivers/hammerdrills are professional power
tool
DO nOT let children come into contact with the tool.
Supervision is required when inexperienced operators
use this tool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons
(including children) suffering from diminished
physical, sensory or mental abilities; lack of
experience, knowledge or skills unless they are
supervised by a person responsible for their safety.
Children should never be left alone with this product.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
WARNING:Use only DeWALT battery packs and
chargers.
Inserting and Removing the Battery
Pack from the Tool (Fig. B)
nOTE: Make sure your battery pack 1 is fully charged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack 1 with the rails inside the tool’s
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly
seated in the tool and ensure that you hear the lock
snap into place.
To Remove the Battery Pack from the Tool
1. Press the release button 2 and firmly pull the battery
pack out of the tool handle.
2. Insert battery pack into the charger as described in the
charger section of this manual.
Fuel Gauge Battery Packs (Fig. B)
Some DeWALT battery packs include a fuel gauge which
consists of three green LED lights that indicate the level
of charge remaining in the battery pack.
To actuate the fuel gauge, press and hold the fuel gauge
button 14 . A combination of the three green LED lights
will illuminate designating the level of charge left. When
the level of charge in the battery is below the usable
limit, the fuel gauge will not illuminate and the battery
will need to be recharged. nOTE: The fuel gauge is only
Battery pack release button
Forward/reverse control button
