9
ENGLISH
Labels on Charger and Battery Pack
In addition to the pictographs used in this manual, the
labels on the charger and the battery pack may show the
followingpictographs:
L
Read instruction manual beforeuse.
p
See Technical Data for chargingtime.
q
Do not probe with conductiveobjects.
r
Do not charge damaged batterypacks.
s
Do not expose towater.
t
Have defective cords replacedimmediately
u
Charge only between 4˚C and 40˚C.
v
Only for indooruse.
x
Discard the battery pack with due care for
theenvironment.
y
Charge DeWALT battery packs only with designated
DeWALT chargers. Charging battery packs other than
the designated DeWALT batteries with a DeWALT
charger may make them burst or lead to other
dangeroussituations.
z
Do not incinerate the batterypack.
B
USE (without transport cap). Example: Wh rating
indicates 108Wh (1battery with 108Wh).
A
TRANSPORT (with built‑in transport cap). Example: Wh
rating indicates 3x 36Wh (3batteries of 36Wh).
Battery Type
The following tools operate on a 18(20 Max) volt battery pack:
DCD800, DCD805.
These battery packs may be used: DCB181, DCB182, DCB183,
DCB184, DCB203, DCB204, DCB205, DCB185,DCB186, DCB187,
DCB189, DCB240,DCBP034, DCB546, DCB547, DCB548, DCB549
,DCB606,DCB609,DCB612,DCB615. Refer to Technical Data for
moreinformation.
Package Contents
The package contains:
1 Drill/driver or 1 drill/driver/hammerdrill
1 Charger
1 Kitbox
1 Li‑Ion battery pack (C1, D1, E1, L1, M1, P1, S1, T1, X1, Y1
models)
2 Li‑Ion battery packs (C2, D2, E2, L2, M2, P2, S2, T2, X2, Y2
models)
3 Li‑Ion battery packs (C3, D3, E3, M3, P3, S3, T3, X3, Y3 models)
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DeWALT is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Markings on Tool
The following pictograms are shown on the tool:
a
Read instruction manual beforeuse.
n
Visible radiation. Do not stare intolight.
Date Code Position (Fig.B)
The date code
14
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2021XX XX
Year and Week of Manufacture
Description (Fig.A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Trigger switch
2
Forward/reverse control button
3
Torque adjustment collar
4
Gear shifter
5
Worklight
6
Keyless chuck
7
Chuck sleeve
8
Belt hook
9
Mounting screw
10
Bit holder
11
Battery pack
12
Battery release button
13
Worklight switch
Intended Use
These drills/drivers/hammerdrills are designed for professional
drilling, percussion drilling and screwdrivingapplications.
