ENGLISH
5
The vibration emission level given in this information sheet has been measured in accordance with a
standardised test given in EN 60745 and may be used to compare one tool with another. It may be used for
a preliminary assessment of exposure.
WARNING: The declared vibration emission level represents the main applications of the
tool. However if the tool is used for different applications, with different accessories or poorly
maintained, the vibration emission may differ. This may significantly increase the exposure level
over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when
the tool is switched off or when it is running but not actually doing the job. This may significantly
reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as:
maintain the tool and the accessories, keep the hands warm, organisation of work patterns.
Battery pack DCB140 DCB141 DCB142 DCB180 DCB181 DCB182 DCB183
Battery type Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion Li-Ion
Voltage V
DC
14.4 14.4 14.4 18 18 18 18
Capacity A
h
3.0 1.5 4.0 3.0 1.5 4.0 2.0
Weight kg 0.53 0.30 0.54 0.64 0.35 0.61 0.40
Charger DCB105
Mains voltage V
AC
230 V
Battery type Li-Ion
Approx. charging time min 30 45 55 70
(1.5 Ah (2.0 Ah (3.0 Ah (4.0 Ah
battery packs) battery packs) battery packs) battery packs)
Weight kg 0.49
Fuses:
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 3 Amperes, in plugs
Defi nitions: Safety Guidelines
The definitions below describe the level of severity
for each signal word. Please read the manual and
pay attention to these symbols.
DANGER: Indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
NOTICE: Indicates a practice not
related to personal injury which, if
not avoided, may result in property
damage.
Denotes risk of electric shock.
Denotes risk of fire.
EC-Declaration of Conformity
MACHINERY DIRECTIVE
DCH143, DCH243, DCH253, DCH254
DEWALT declares that these products described
under Technical Data are in compliance with:
2006/42/EC, EN 60745-1, EN60745-2-6.
These products also comply with Directive
2004/108/EC and 2011/65/EU. For more
information, please contact DEWALT at the following
address or refer to the back of the manual.
The undersigned is responsible for compilation of the
technical file and makes this declaration on behalf of
DEWALT.

DeWalt DCH253 Specifications

General

Power source	Battery
Battery voltage	18 V
Impact rate	4500 bpm
Rated speed (max)	1200 RPM
Impact energy (max)	2.1 J
Drilling diameter in wood (max)	26 mm
Drilling diameter in steel (max)	13 mm
Vibration level (metal drilling)	2.5 m/s²
Vibration level (hammer drilling)	6.6 m/s²
Drilling diameter in concrete (max)	24 mm
Reverse	Yes
Product color	Black, Yellow

Weight and Dimensions

Depth	301 mm
Width	85 mm
Height	202 mm
Weight	2500 g
