DeWalt DCH333 Original Instructions

11
ENGLISH
To Install the Battery Pack into the
Tool Handle
1. Align the battery pack
6
with the rails inside the tool’s
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the release button
7
and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs
Some DeWALT battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button
19
. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
Side Handle (Fig.A)

WARNING: To reduce the risk of personal injury, ALWAYS
operate the tool with the side handle properly installed.
Failure to do so may result in the side handle slipping
during tool operation and subsequent loss of control. Hold
tool with both hands to maximizecontrol.
The side handle
5
clamps to the front of the gear case and
may be rotated 360˚ to permit right- or left-hand use. The side
handle must be tightened sufficiently to resist the twisting
action of the tool if the accessory binds or stalls. Be sure to grip
the side handle at the far end to control the tool during astall.
To loosen side handle, rotatecounterclockwise.
To Adjust the Depth Rod (Fig. C)
1. Push in and hold the depth rod release button
12
on the
sidehandle.
2. Move the depth rod
11
so the distance between the
end of the rod and the end of the bit equals the desired
drillingdepth.
3. Release the button to lock rod into position. When drilling
with the depth rod, stop when end of rod reaches surface
ofmaterial.
Utility Hook (Fig.A,D)
A utility hook
14
is fitted below the main handle
8
on the left
side of the tool. To extend the utility hook pull it out from the
side of the tool. To store the utility hook push it back flush with
the side of thetool. If use of the hook is not desired at all, it can
be removedcompletely.
To Remove and/or Reinstall the
Utility Hook
1. Position the utility hook into the extended position and
remove the hex head screw located on the underside of the
mainhandle.
2. Pull out the utility hook until it is free from theunit.
3. To reinstall, insert the utility hook into the the slot below the
mainhandle.
Bit and Bit Holder

WARNING: Burn Hazard. ALWAYS wear gloves when
changing bits. Accessible metal parts on the tool and bits
may get extremely hot during operation. Small bits of
broken material may damage barehands.
The hammerdrill can be fitted with different bits depending on
the desired application. Use sharp drill bitsonly.
Bit Reccomendations
• For wood, use twist bits, spade bits, power auger bits or
holesaws.
• For metal, use high-speed steel twist drill bits or holesaws.
Use a cutting lubricant when drilling metals. The exceptions
are cast iron and brass which should be drilleddry.
• For masonry, such as brick, cement, cinder block, etc., use
carbide-tipped bits rated for percussiondrilling.
SDS-Plus Bit Holder (Fig. F)
NOTE: Special adapters are needed to use the SDS-plus tool
holder with straight shank bits and hexagonal screwdriver bits.
Refer to OptionalAccessories.
To insert a drill bit or other accessory:
1. Insert the shank of the bit about 19mm into SDS-Plus
toolholder.
2. Push and rotate bit until it locks in place. The bit will be
securelyheld.
3. To release bit, pull the sleeve
10
back and remove thebit.
Keyless Chuck (Fig. F, G)
DCH334
On some models, a keyless chuck can be installed in place of the
SDS-Plus bitholder.

WARNING: Never use standard chucks in the rotary
hammeringmode.
Replacing the SDS-Plus Bit Holder with the Keyless Chuck
1. Select hammering only mode (see Operation Modes), this
locks the spindle to prevent it from rotating when unlocking
the removable toolholder.
2. Turn the locking collar
15
into the unlocked position and
pull the installed bit holderoff.
3. Push the keyless chuck
16
onto the spindle
17
and turn
the locking collar into the lockingposition.
4. To replace the keyless chuck with the SDS-Plus bit holder,
first remove the keyless chuck the same way as the SDS-
Plus bit holder was removed. Then replace the SDS-Plus
bitholder the same way as the keyless chuck wasreplaced.
