10
ENGLISH
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Trigger switch
2
Side handle
3
Front Barrel (Collar)
4
Mode selector dial
5
Main handle
6
Bit holder
7
Sleeve
8
Battery pack
9
Battery release button
10
Electronic speed and
impact control dial
11
Red anti-rotation system
indicator LED
12
Yellow service indicator
LED
13
DeWALT tool tag mounting
holes
14
Date code
Intended Use
Your rotary hammer has been designed for professional
rotary masonry and concrete drilling, chiseling and
chippingapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
Your rotary hammer is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
Date Code Position (Fig.A)
The production date code
14
consists of a 4-digit year followed
by a 2-digit week and is extended by a 2-digit factory code.
Markings on Tool
The following pictograms are shown on the tool:
a
Read instruction manual beforeuse.
g
Wear earprotection.
f
Wear eyeprotection
1 Li-Ion battery pack (C1, D1, E1, G1, H1, L1, M1, P1, Q1, S1, T1,
U1, X1, Y1, Z1 models)
2 Li-Ion battery packs (C2, D2, E2, G2, H2, L2, M2, P2, Q2, S2, T2,
U2, X2, Y2, Z2 models)
3 Li-Ion battery packs (C3, D3, E3, G3, H3, L3, M3, P3, Q3, S3, T3,
U3, X3, Y3, Z3 models)
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DeWALT is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Package Contents
The package contains:
1 Rotary Hammer
1 Side handle
1 Charger
Battery Type
The following tools operate on a 54-volt battery pack:
DCH735., DCH775
These battery packs may be used: DCB546, DCB547, DCB547G,
DCB548, DCB549. Refer to Technical Data for moreinformation.
NOTE: Battery packs should not be stored completely depleted
of charge. The battery pack will need to be recharged beforeuse.
Labels on Charger and Battery Pack
In addition to the pictographs used in this manual, the
labels on the charger and the battery pack may show the
followingpictographs:
L
Read instruction manual beforeuse.
p
Refer to Technical Data for chargingtime.
q
Do not probe with conductiveobjects.
r
Do not charge damaged batterypacks.
s
Do not expose towater.
t
Have defective cords replacedimmediately.
u
Charge only between 4˚C and 40˚C.
v
Only for indooruse.
x
Discard the battery pack with due care for
theenvironment.
y
Charge DeWALT battery packs only with designated
DeWALT chargers. Charging battery packs other than
the designated DeWALT batteries with a DeWALT
charger may make them burst or lead to other
dangeroussituations.
z
Do not incinerate the batterypack.
B
USE (without transport cap). Example: Wh rating
indicates 108Wh (1battery with 108Wh).
A
TRANSPORT (with built-in transport cap). Example: Wh
rating indicates 3x 36Wh (3batteries of 36Wh).
