DeWalt DCS7485

18
ENGLISH
6. Use the small set screws
33
to adjust the riving knife
position. Lay the straight edge on the opposite side of the
blade and repeat adjustments asneeded.
7. Lightly tighten the two larger lock screws
35
.
8. Place a square flat against the riving knife to verify the riving
knife is vertical and in-line with theblade.
9. If needed, use the set screws to bring the riving knife vertical
with thesquare.
10. Repeat step 4 to verify position of rivingknife. Repeat 5
thru9 ifnecessary.
11. Fully tighten the two larger lock screws
35
.
Parallel Adjustment (Fig. A, I, J)
For optimum performance, the blade must be parallel to the
rip fence. This adjustment has been made at the factory. To
re-adjust:
Position 1 Fence Alignment
1. Install the fence in position 1 and unlock the rail lock
lever
5
. Locate both locator pins
31
that support the fence
on the front and rearrails.
2. Loosen the rear locator pin screw and adjust the allignment
of the fence in the groove until the fence face is parallel to
the blade. Make sure you measure from the fence face to
the front and back of the blade to ensurealignment.
3. Tighten the locator screw and repeat on the left side of
theblade.
4. Check rip scale pointer adjustment(Fig.J).
Position 2 Fence Alignment (Fig. I)
1. To align position 2 fence locator pins
31
, ensure
position 1 pins have been aligned, refer to Position 1
FenceAlignment.
2. Loosen the position 2 pins, then using the holes on the
blade wrench
21
as a guide for positioning, align the
pins(Fig.I).
3. Tighten the locator pins(front and rear).
Adjusting the Rip Scale (Fig. J)
1. Unlock the rail lock lever
5
.
2. Set the blade at 0° bevel and move the fence in until it
touches theblade.
3. Lock the rail locklever.
4. Loosen the rip scale indicator screws
36
and set the rip
scale indicator to read zero(O). Retighten the rip scale
indicator screws. The yellow rip scale(top) reads correctly
only when the fence is mounted on the right side of the
blade and is in position 1 (for 0mm to 510mm ripping) not
the 610mm rip position. The white scale(bottom) reads
correctly only when the fence is mounted on the right
side of the blade and in position 2 (for position100mm to
610mm ripping).
The rip scale reads correctly only when the fence is mounted to
the right of theblade.
Rail Lock Adjustment (Fig. J, K)
The rail lock has been factory-set. If you need to re-adjust,
proceed as follows:
1. Lock the rail lock lever
5
.
2. On the underside of the saw, loosen the jam nut
37
.
3. Tighten the hex rod
38
until the spring on the locking
system is compressed creating the desired tension on the
rail lock lever. Retighten the jam nut against the hexrod.
4. Flip the saw over and check that the fence does not move
when the lock lever is engaged. If the fence is still loose,
tighten the springfurther.
Bevel Stop And Pointer Adjustment (Fig. L)
1. Raise the blade fully by rotating the blade height
adjustment wheel
6
clockwise until itstops.
2. Unlock the bevel lock lever
7
by pushing it up and to the
right. Loosen the bevel stop screw
39
.
3. Place a square flat against the table top and against the
blade between teeth. Ensure the bevel lock lever is in its
unlocked, or up, position.
4. Using the bevel lock lever, adjust the bevel angle until it is
flat against thesquare.
5. Tighten the bevel lock lever by pushing itdown.
6. Turn the bevel stop screw
39
to rotate the cam until it
firmly contacts the bearing block. Tighten the bevel stop
screw.
7. Check the bevel angle scale. If the pointer does not read 0°,
loosen pointer screw
40
and move the pointer so it reads
correctly. Retighten the pointerscrew.
8. Repeat at 45°, but do not adjustpointer.
Mitre Gauge Adjustment (Fig. A)
To adjust mitre gauge
10
loosen knob, set to desired angle and
tightenknob.
Body and Hand Position
Proper positioning of your body and hands when operating the
table saw will make cutting easier, more accurate andsafer.

WARNING:
• Never place your hands near the cuttingarea.
• Place your hands no closer than 150mm from
theblade.
• Do not cross yourhands.
• Keep both feet firmly on the floor and maintain
properbalance.
Prior to Operation

WARNING:
• Install the appropriate saw blade. Do not use
excessively worn blades.The maximum rotation speed
of the tool must not exceed that of the sawblade.
• Do not attempt to cut excessively smallpieces.
• Allow the blade to cut freely. Do notforce.
• Allow the motor to reach full speed beforecutting.
