27
ENGLISH
English (original instructions)
CORDLESS COMPACT MITRE SAW
DCS777
Congratulations!
You have chosen a
tool. Years of experience, thorough product
development and innovation make
one of the most reliable
partners for professional power toolusers.
Technical Data
DCS777
Voltage V 54
Type 1
XPS Yes
Power output W 1750
Blade diameter mm 216
Blade bore mm 30
Max. blade speed min
-1
6300
Mitre (max. positions) left and right 50°
Bevel (max. positions) left 48°
Compound mitre bevel 45°
mitre 45°
Capacities
cross-cut 90° mm 60 x 270
mitre 45° mm 60 x 190
mitre 48° mm 60 x 180
bevel 45° mm 48 x 270
bevel 48° mm 45 x 270
Overall dimensions mm 460 x 560 x 430
Weight kg 15.0
Noise values and vibration values (triax vector sum) according to EN61029:
L
PA
(sound pressure) dB(A) 93
L
WA
(acoustic power) dB(A) 103
K (acoustic power uncertainty) dB(A) 3.0
The noise emission level given in this information sheet has been measured
in accordance with a standardised test given in EN61029 and may be
used to compare one tool with another. It may be used for a preliminary
assessment of exposure.
WARNING: The declarednoise emission level represents the main
applications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained, the noise
emission may differ. This may significantly increase the exposure level
over the total working period.
An estimation of the level of exposure to vibration should also take into
account the times when the tool is switched off or when it is running
but not actually doing the job.
This may significantly reduce the exposure level over the total working
period. Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work patterns.
Battery pack DCB546
Battery type Li-Ion
Voltage V
DC
18/54
Capacity Ah 6.0/2.0
Weight kg 1.05
Charger DCB118
Mains voltage V
AC
230
Battery type 18/54 Li-Ion
Approx. charging time of
battery packs
min 22 (1.3 Ah) 22 (1.5 Ah) 30 (2.0 Ah)
45 (3.0 Ah) 60 (4.0 Ah) 75 (5.0 Ah)
60 (6.0 Ah)
Weight kg 0,66
The DCB118 charger accepts 18V Li-Ion XR and XRFLEXVOLT
TM
battery
packs (DCB181, DCB182, DCB183, DCB183B, DCB184, DCB184B, DCB185
and DCB546).
Fuses:
Europe 230V tools 10 Amperes. mains
U.K. & Ireland 230V tools 3 Amperes. in plugs
EC-Declaration of Conformity
Machinery Directive
Cordless Compact Mitre Saw
DCS777
declares that these products described under Technical Data are
in compliance with:
2006/42/EC, EN61029-1:2009 + A11:2010, EN61029-2-9:2012 + A11:2013.
These products also comply with Directive, 2014/30/EU and 2011/65/EU.
For more information, please contact
at the following address or
refer to the back of themanual.
The undersigned is responsible for compilation of the technical file and
makes this declaration on behalf of
.
Markus Rompel
Director Engineering
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
20.07.2016
WARNING: To reduce the risk of injury, read the instructionmanual.
Safety Instructions
WARNING: Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in electric shock,
fire and/or seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
General Safety Rules
1 . Keep work areaclear.
Cluttered areas and benches inviteinjuries.
2 . Consider work areaenvironment.
Do not expose the tool to rain. Do not use the tool in damp or wet
conditions. Keep the work area well lit (250–300 Lux). Do not use the tool
where there is a risk of causing fire or explosion, e.g., in the presence of
flammable liquids andgases. Work area should be wellventilated.
