DeWalt DCV501 User Manual

9
ENGLISH
Cleaning/Emptying the Dust Bowl and
Filter (Fig.D, E, J, K)

WARNING: Projectile/Respiratory Hazard: Never use
the vac without itsfilter.
NOTE: The filter is reusable, do not confuse it with a
disposable dust bag, and do not throw it away when the
product is emptied. We recommend that you replace the
filter every 6–9 months depending on frequency ofuse.
Removing Filter
1. Place the vacuum over a trash bin and remove the
dust bowl
2
from the main housing by pressing the
dust bowl release button
3
on the handle and remove
the dust bowl by pulling the dust bowl away from the
mainhousing.
2. Remove the filter assembly
4
by pulling it out of the
dustbowl.
3. Twist counterclockwise and pull the filter cap
21
to
seperate it from thefilter
20
.
Install Filter
1. Attach the filter cap onto the filter and rotate it clockwise
to lock it firmly intoposition.
2. Push the filter assembly into the dustbowl.
3. Install the dust bowl onto the main housing and lock it
firmly intoposition.
Cleaning
IMPORTANT: Maximum dust collection will only be
obtained with a clean filter and an empty dust bowl. If dust
begins to fall back out of the product after it is switched off,
this indicates that the bowl is full and requiresemptying.
1. Once the filter is removed from the dust bowl, shake off
or lightly brush any dust from thefilter.
2. Empty any dust from the dust bowl
2
into a trashbin
and wash ifnecessary.
3. Rinse out the dust bowl with warm soapywater. Ensure
that the dust bowl is completely dry beforeusing.
4. Wash the filters regularly using warm, soapy water and
ensure that it is completely dry before using again. The
cleaner the filter is, the better the product will perform.
5. It is very important that the filters are completely dry and
correctly in position beforeuse.
6. Ensure the filters are completely dry for 12hours
beforerefitting.
Replacement HEPA filter: DCV5011H
Cleaning

WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk
of eye injury, always wear ANSI Z87.1approved eye
protection when performingthisprocedure.

WARNING: Never use solvents or other harsh
chemicals for cleaning the non‑metallic parts of the
tool. These chemicals may weaken the plastic materials
used in these parts. Use a cloth dampened only with
water and mild soap. Never let any liquid get inside the
tool; never immerse any part of the tool into aliquid.
Storing the Dust Extractor

WARNING:
a ) Empty the dust collection box before storing the dust
extractor.
b ) Always store your dust extractor with the batteries
removed.
c ) Store the tool and batteries in a place that is as cool
and dry as possible.
d ) Store the tool and batteries in a place that cannot be
accessed by children or unauthorised persons.
e ) Check the tool and batteries for damage after long
periods of storage.
f ) Refer to the Battery Packs, Transportation section of
this manual for further information.
MAINTENANCE

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can causeinjury.
Your DeWALT power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.
On/Off Switch (Fig. I)
NOTE: This product is for dry pick‑up only.
• To switch the vac on, slide the On/Off switch
1
forward.
• To switch the vac off, slide the On/Off switch back.
Installing and Removing the Battery Pack
(Fig.H)
NOTE: For best results, make sure your battery pack is
fullycharged.
To install the battery pack
5
into the tool handle, align the
battery pack with the rails inside the tool’s handle and slide it
into the handle until the battery pack is firmly seated in the
tool and ensure that it does notdisengage.
To remove the battery pack from the tool, press the release
button
6
and firmly pull the battery pack out of the tool
handle. Insert it into the charger as described in the charger
section of thismanual.
OPERATION FIG. A

WARNING: To Reduce The Risk Of Electric Shock –
Use indoorsonly.

WARNING: To reduce the risk of serious personal
injury, turn unit OFF before making any
adjustments or removing/installing attachments
or accessories. An accidental start‑up can
causeinjury.

WARNING: Projectile/Respiratory Hazard: Never use
the vac without itsfilter.
