DeWalt DWE1622K - Motor, Intended Use, and Assembly; Assembly and Adjustments Overview

30
English
WARNING: Use of this tool can generate and/or disburse dust,
which may cause serious and permanent respiratory or other injury.
AlwaysuseNIOSH/OSHAapprovedrespiratoryprotectionappropriate
for the dust exposure. Direct particles away from face and body.
WARNING: ALWAYS USE SAFETY GLASSES. Everyday
eyeglassesareNOTsafetyglasses.Also use face ordustmaskif
cuttingoperationisdusty.AllusersandbystandersMUSTALWAYS
wear certified safety equipment:
• ANSIZ87.1eyeprotection(CAN/CSAZ94.3),
• ANSIS12.6(S3.19)hearingprotection,
• NIOSH/OSHA/MSHArespiratoryprotection.
WARNING: Always wear proper personal hearing protection
that conforms to ANSI S12.6 (S3.19) during use. Under some
conditions and duration of use, noise from this product may
contribute to hearing loss.
• The label on your tool may include the following symbols. The
symbols and their definitions are as follows:
V ............. volts A .............amperes
Hz........... hertz W ...........watts
min ......... minutes
..........alternating current
....... direct current
n
o ........... no load speed
........... ClassIConstruction n ............rated speed
............... (grounded)
...........earthing terminal
............ ClassIIConstruction ...........safety alert symbol
............... (double insulated) …/min ....revolutions or
IPM ........ impacts per minute ............... reciprocation
SPM ...... strokes per minute BPM .......beats per minute
sfpm ...... surface feet .............. per minute
.............. per minute (sfpm)
SAVE THESE INSTRUCTIONS FOR
FUTUREUSE
Motor
Be sure your power supply agrees with the nameplate marking.
Voltage decrease of more than 10% will cause loss of power and
overheating. D
e
WALT tools are factory tested; if this tool does not
operate, check power supply.
DESCRIPTION (Fig. 1, 5)
WARNING: Nevermodifythepowertooloranypartofit.Damage
or personal injury could result.
A. ON/OFF power/magnet
switch
B. Off button for motor
C. On button for motor
D. Gear selector
E. Magnetic bracket
F. Feed handle
G. Hub
H. Tool holder
I. Guard
J. Coolant bottle
K. Coolant tube
L. Quick release connector
M. Flow regulator
N. LED indicator light
O. Safety chain (Fig. 5)
INTENDED USE
DO NOT use under wet conditions or in presence of flammable
liquids or gases.
DO NOT let children come into contact with the tool. Supervision is
required when inexperienced operators use this tool.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of injury, turn unit off
and disconnect it from power source before installing and
removing accessories, before adjusting or when making
repairs.Anaccidentalstart-upcancauseinjury.
WARNING: Prior to assembly and adjustment, ALWAYS unplug
tool.
