ENGLISH
25
DWS520 PLUNGE SAW
Congratulations!
You have chosen a DEWALT tool. Years of
experience, thorough product development and
innovation make D
EWALT one of the most reliable
partners for professional power tool users.
Technical data
DWS520 DWS520
QS/GB LX
Voltage V
DC
220-240 115
Power W 1300 1300
No-load speed min
-1
1750-4000 1750-4000
Blade diameter mm 165 165
Maximum depth of cut
90˚ (without guide rail) mm 59 59
90˚ (with guide rail) mm 55 55
Blade bore mm 20 20
Bevel angle adjustment 47˚ 47˚
Weight kg 5 5
Fuses:
Europe 230 V tools 10 Amperes, mains
U.K. & Ireland 230 V tools 13 Amperes, in plugs
Defi nitions: Safety Guidelines
The definitions below describe the level of severity
for each signal word. Please read the manual and
pay attention to these symbols.
DANGER: Indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
CAUTION: Used without the safety alert
symbol indicates a potentially hazardous
situation which, if not avoided, may
result in property damage.
Denotes risk of electric shock.
Denotes risk of fire.
DWS520 DWS520
QS/GB LX
L
pA
(sound pressure) dB(A 92 92
K
pA
(sound pressure uncertainty) dB(A) 3 3
L
WA
(acoustic power) dB(A) 103 103
K
WA
(acoustic power uncertainty) dB(A) 3 3
Vibration total values (triax vector sum)
determined according to EN 60745:
DWS520 Vibration emission value = 2.8 m/s²
Uncertainty K = 1.5 m/s²
The declared vibration emission value has been
measured in accordance with a standard test
method and may be used for comparing one tool
with another.
The declared vibration emission value may also be
used in a preliminary assessment of exposure.
WARNING: The vibration emission
value during actual use of the power
tool can differ from the declared value
depending on the ways in which the tool
is used. This could lead to a significant
underestimate of exposure when the
tool is used regularly in such a way.
An estimation of the level of exposure to vibration
experienced during a given period of work should
also take into account the times when the tool is
switched off and when it is running idle in addition to
the trigger time.
This may significantly reduce the exposure level over
the total working period.
EC-Declaration of conformity
DWS520
DEWALT declares that these tools have been
designed in compliance with:
2006/95/EC, 98/37/EC, 2004/108/EC,
EN 60745-1, EN 60745-2-5, EN 55014-1: 2006,
EN 55014-2:1997 + A1:2001, EN 61000-3-2: 2006,
EN 61000-3-3: 1995 + A1: 2001.
