ENGLISH
29
– Risk of accidents caused by the uncovered
parts of the rotating cutting disc.
– Risk of injury when changing the disc.
– Risk of dust inhalation from materials that
when cut, can be harmful.
Labels on tool
In addition to the pictographs used in this
manual, the labels on the tool show the following
pictographs:
Maximum depth of cut
Blade diameter
Package contents
The package contains:
1 Plunge saw
1 Rail clamp
1 Allen key
1 Instruction manual
1 Exploded drawing
• Check for damage to the tool, parts or
accessories which may have occurred during
transport.
• Take the time to thoroughly read and
understand this manual prior to operation.
Description (fi g. 1–3)
WARNING: Never modify the power
tool or any part of it. Damage or
personal injury could result.
INTENDED USE
The DWS520 plunge saw is designed for
professional sawing applications and cutting wood
products.
DO NOT use under wet conditions or in presence of
flammable liquids or gases.
This heavy-duty plunge saw is a professional power
tool. DO NOT let children come into contact with
the tool. Supervision is required when inexperienced
operators use this tool.
a. plunge trigger
b. on/off switch
c. main handle
d. shoe
e. bevel adjustment knob
f. depth adjustment knobs
g. depth scale
h. front handle
i. dust extraction outlet
j. rail adjuster
k. blade
l. lock button
m. lock lever
n. blade clamping screw
o. outer flange
p. inner flange
q. riving knife
r. riving knife adjustment screws
s. speed wheel
t. cutting indicator
u. anti-kickback knob
v. outer guard
w. guide rail
x. clamp
y. blade position indicators
Electrical safety
The electric motor has been designed for one
voltage only. Always check that the power supply
corresponds to the voltage on the rating plate.
Your DEWALT tool is double insulated in
accordance with EN 60745; therefore no
earth wire is required.
If the supply cord is damaged, it must be replaced
by a specially prepared cord available through the
DEWALT service organization.
Mains plug replacement
(U.K. & Ireland only)
DANGER:
• Should your mains plug need replacing and you
are competent to do this, proceed as instructed
below. If you are in doubt, contact an authorized
D
EWALT repair agent or a qualified electrician.
• Disconnect the plug from the supply.
• Cut off the plug and dispose of it safely; a plug
with bared copper conductors is dangerous if
engaged in a live socket outlet.
