20
3. If the unit detects that the alternator is good, the LCD Screen shows
the following:
The Alternator Icon, “ALT GOOD” and the (full) Battery Icon will light
solid.
4. If the unit detects that the alternator is out of typical voltage range,
the LCD Screen shows the following:
The Fault Icon will flash. The Alternator Icon, “ALT” and the (empty)
Battery Status Icon will light solid.
5. Press the Alternator Check Button again to stop the check.
PART 2
Under Load (accessories ON): Next, load the alternator by turning
on as many accessories as possible (except for the A/C and Defrost).
1. Refer to the “Charging the Battery” section of this Instruction
Manual. Set up the battery charger and connect to the battery
following steps 1 and 2. The unit will be in Standby Mode.
2. Press the Alternator Check Button to start the check. The Digital
Display shows the following to indicate the unit is analyzing the
alternator:
The Alternator Icon will flash and the Battery icon with two bars will
light solid.
3. If the unit detects that the alternator is good, the LCD Screen
shows the following:
The Alternator Icon, “ALT GOOD” and the (full) Battery Icon will light
solid.
DXAEC210_ManualENFRSP_092116.indd 20 10/19/2016 3:58:54 PM
