DeWalt XR Li-Ion DCD991 User Manual

11
English
WARNING: 120 V units have to
be operated via a fail-safe isolating
transformer with an earth screen
between the primary and secondary
winding.
If the supply cord is damaged, it must be replaced
by a specially prepared cord available through the
D
e
WALT service organization.
Mains Plug Replacement
(Middle East and Africa)
If a new mains plug needs to be fitted:
 • Safelydisposeoftheoldplug.
 • Connectthebrownleadtotheliveterminalin
the plug.
 • Connecttheblueleadtotheneutralterminal.
WARNING: No connection is to be
made to the earth terminal.
Follow the fitting instructions supplied with good
quality plugs. Recommended fuse: 3 A.
Using an Extension Cable
An extension cord should not be used unless
absolutely necessary. Use an approved extension
cable suitable for the power input of your charger
(see Technical Data). The minimum conductor size
is 1 mm
2
; the maximum length is 30 m.
When using a cable reel, always unwind the cable
completely.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of
serious personal injury, turn tool
off and disconnect battery pack
before making any adjustments or
removing/installingattachmentsor
accessories. An accidental start-up
can cause injury.
WARNING: Use only D
e
WALT battery
packs and chargers.
Inserting and Removing the
Battery Pack from the Tool (Fig. 2)
NOTE: For best results, make sure your battery
pack is fully charged.
TO INSTALL THE BATTERY PACK INTO THE TOOL HANDLE
1. Align the battery pack (H) with the rails inside
the tool’s handle (Fig. 2).
2. Slide it into the handle until the battery pack is
firmly seated in the tool and ensure that it does
not disengage.
B. Forward/reverse control button
C. Worklight
D. Chuck
E. Torque adjustment collar
F. Gear shifter
G. Side handle
H. Battery pack
I. Battery release button
J. Belt hook
K. Mounting screw
L. Magnetic bit holder
M. Worklight switch
N. Low worklight mode
O. Medium worklight mode
P. Spotlight mode
Q. Fuel gauge
R. Main handle
INTENDED USE
These drills drivers/hammerdrills are designed
for professional drilling, percussion drilling and
screwdriving applications.
DO NOT use under wet conditions or in presence of
flammable liquids or gases.
These drills/drivers/hammerdrills are professional
power tools.
DO NOT let children come into contact with the
tool. Supervision is required when inexperienced
operators use this tool.
 • Young children and the infirm. This appliance
is not intended for use by young children or
infirm persons without supervision.
 •Thisproductisnotintendedforusebypersons
(including children) suffering from diminished
physical, sensory or mental abilities; lack of
experience, knowledge or skills unless they are
supervised by a person responsible for their
safety. Children should never be left alone with
this product.
Electrical Safety
The electric motor has been designed for one
voltage only. Always check that the battery pack
voltage corresponds to the voltage on the rating
plate. Also make sure that the voltage of your
charger corresponds to that of your mains.
Your D
e
WALT charger is double insulated
in accordance with EN60335; therefore
no earth wire is required.

DeWalt XR Li-Ion DCD991 Specifications

General

Voltage	18 V
Battery Type	XR Li-Ion
Chuck Size	1/2 inch
Speed Settings	3
LED Light	Yes
Chuck Capacity	1/2 inch
Power Output	820 UWO
Battery Chemistry	Lithium-Ion
Max Torque (UWO)	820 UWO
Max RPM	2000 RPM
No Load Speed (RPM)	0-450 / 0-1300 / 0-2000 RPM
Length	213 mm
