DeWalt XR LI-ION DCN680 Original Instructions

11
ENGLISH
Proper Hand Position (Fig.F)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
Inserting and Removing the Battery Pack
from the Tool (Fig.B)
NOTE: Make sure your battery pack
14
is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack
14
with the rails inside the tool’s
handle (Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the release button
15
and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig.B)
Some DEWALT battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button
 
. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end‑userapplication.

WARNING: Disconnect battery pack from tool before
making any adjustments, changing accessories,
servicing, or moving the tool. Such preventative safety
measures reduce the risk of starting the toolaccidentally.

CAUTION: When not in use, place tool on its side on
a stable surface where it will not cause a tripping
or falling hazard. Some tools with large battery packs
will stand upright on the battery pack but may be easily
knockedover.
Belt Hook (Fig.A)
The cordless nailers include an integrated belt hook and can
be attached to either side of the tool to accommodate left‑ or
right‑handedusers.
If the hook is not desired at all, it can be removed from thetool.
To Remove Belt Hook
1. Remove battery pack fromtool.
2. To switch the tool from right‑ to left‑hand usage simply
remove the screw
19
from the opposite side of the tool and
reassemble on the otherside.
3. Replace batterypack.

WARNING: Remove nails from magazine before making
any adjustments or servicing this tool. Failure to do so may
result in seriousinjury.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.

WARNING: Use only DEWALT battery packs andchargers.
Description (Fig.A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Trigger
2
Trigger lock‑off
3
Depth adjustment wheel
4
Headlights/low battery/
stallindicator
5
Jam clearing latch
6
Contact trip
7
Sliding magazine
8
Bump/sequential
selectorswitch
9
Reversible belt hook
10
No‑mar pad
11
No‑mar pad storage
12
Stall release lever
13
Nail depth indicator
14
Battery
15
Battery release button
16
Magazine latch
17
Low nail indicator
Intended Use
Your cordless finish nailer has been designed for driving nails
into woodenworkpieces.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
Your cordless finish nailer is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.

DeWalt XR LI-ION DCN680 Specifications

General

Type	Cordless Brad Nailer
Battery Type	20V MAX Lithium-Ion
Nail Diameter	18 gauge
Magazine Capacity	110 nails
Tool-Free Jam Release	Yes
Battery Included	No
Charger Included	No
Firing Mode	Sequential
Depth Adjustment	Yes
Nail Length	5/8" to 2-1/8"
Weight	5.3 lbs (without battery)
