DeWalt XR LI-ION DCN680 Original Instructions

13
ENGLISH
D
Cleaning

WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
C
Lubrication
Your power tool requires no additionallubrication.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
The charger and battery pack are notserviceable.
3. Lift the jam clear latch
5
then pull up to open the
nosepiecedoor.
4. Remove bent nail, using pliers ifnecessary.
5. If driver blade is in the down position, cycle the stall release
lever
12
using enough force to fully slide it to the other end
of the slot in thehousings.
6. Close the nosepiece door and engage the latch pin under
the two arms on the nosepiece. Push latch until it locks
inplace.
7. Reinsert batterypack.
NOTE: The tool will disable itself and not reset until the
battery pack has been removed andreinserted.
8. Reinsert nails into magazine (see Loading theTool).
NOTE: Should nails continue to jam frequently in nosepiece,
have tool serviced by an authorised DEWALT servicecentre.
Cold Weather Operation
When operating tools at temperatures below freezing:
1. Keep tool as warm as possible prior touse.
2. Actuate the tool 5or 6times into scrap timber beforeusing.
Hot Weather Operation
Tool should operate normally. However, keep tool out of direct
sunlight as excessive heat can deteriorate bumpers and other
rubber parts resulting in increasedmaintenance.
Unloading The Tool

WARNING: The trigger lock‑off should always be locked
off whenever any adjustments are made or when tool is
not inuse.
1. Press magazine latch
16
and open sliding
magazine
7
fully.
2. Tip the tool up until the nails slide freely out of the side of
the magazine. Close sliding magazinefully.
3. Open the jam clear door on the nosepiece to verify there are
no nailsremaining.
Dryfire Lock Out Feature (Fig.A)
Your nailer is equipped with a dryfire lock out feature to prevent
it from cycling when there are no fasteners loaded. When
the low nail indicator
17
is visible, the tool is running low on
fasteners. When this happens, the tool will be locked out and
will not actuate until more nails are loaded. (Refer to Loading
the Tool.)
Adjusting Depth (Fig.G)
The depth that the fastener is driven can be adjusted using the
depth adjustment wheel
3
on the side of thetool.

WARNING: To reduce risk of serious injury from
accidental actuation when attempting to adjust
depth, ALWAYS:
• Remove batterypack.
• Engage trigger lock‑off.
• Avoid contact with trigger duringadjustments.
1. To drive the nail shallower
, rotate the depth adjustment
wheel
3
away from the nose of thenailer.
2. To sink a nail deeper
, rotate the depth adjustment
wheel
3
toward the nose of thenailer.
Headlights (Fig.H)
There is a headlight
4
located on each side of the nailer.
Headlights turn on upon battery insertion, activation of
the trigger, or depressing the contact trip. The lights will
automatically shut off after 20seconds unless tool remains
inuse.
NOTE: These headlights are for lighting the immediate work
surface and are not intended to be used asflashlights.
Low battery indicator: The left‑side headlight will flash four
consecutive times and then shut down to indicate lowbattery.
Jammed nail indicator: The right‑side headlight will flash
continually if a nail becomes jammed in the nosepiece
(seeClearing a Stall or JammedNail).
Clearing a Stall or Jammed Nail (Fig.A, F, I)
If a nail becomes jammed in the nosepiece or the tool stalls,
the right‑hand headlight will blink continuously. Keep the tool
pointed away from you and follow these instructions to clear:
1. Remove battery pack from tool and engage the trigger
lock‑off.
2. Press the magazine latch
16
and remove any loadednails.

DeWalt XR LI-ION DCN680 Specifications

General

Type	Cordless Brad Nailer
Battery Type	20V MAX Lithium-Ion
Nail Diameter	18 gauge
Magazine Capacity	110 nails
Tool-Free Jam Release	Yes
Battery Included	No
Charger Included	No
Firing Mode	Sequential
Depth Adjustment	Yes
Nail Length	5/8" to 2-1/8"
Weight	5.3 lbs (without battery)
