DeWalt XR Li-ION DCS331 Original Instructions

28
ENGLISH
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool
and the accessories, keep the hands warm, organisation
of workpatterns.
Battery pack DCB141 DCB142
Battery type Li-Ion Li-Ion
Voltage V
DC
14.4 14.4
Capacity Ah 1.5 4.0
Weight kg 0.30 0.54
Battery pack DCB143 DCB144 DCB145
Battery type Li-Ion Li-Ion Li-Ion
Voltage V
DC
14.4 14.4 14.4
Capacity Ah 2.0 5.0 1.3
Weight kg 0.30 0.52 0.30
Battery pack DCB181 DCB182
Battery type Li-Ion Li-Ion
Voltage V
DC
18 18
Capacity Ah 1.5 4.0
Weight kg 0.35 0.61
Battery pack DCB183/B DCB184/B DCB185
Battery type Li-Ion Li-Ion Li-Ion
Voltage V
DC
18 18 18
Capacity Ah 2.0 5.0 1.3
Weight kg 0.40/0.45 0.62/0.67 0.35
Battery pack DCB546
Battery type Li-Ion
Voltage V
DC
18/54
Capacity Ah 6.0/2.0
Weight kg 1.05
Charger DCB107
Mains voltage V
AC
230
Battery type 10.8/14.4/18 Li-Ion
Approx. charging time of
battery packs
min 60 (1.3 Ah) 70 (1.5 Ah) 90 (2.0 Ah)
140 (3.0 Ah) 185 (4.0 Ah) 240 (5.0 Ah)
Weight kg 0.29
Charger DCB112
Mains voltage V
AC
230
Battery type 10.8/14.4/18 Li-Ion
Approx. charging time of
battery packs
min 40 (1.3 Ah) 45 (1.5 Ah) 60 (2.0 Ah)
90 (3.0 Ah) 120 (4.0 Ah) 150 (5.0 Ah)
Weight kg 0.36
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough
product development and innovation make
DeWALT
one of the
most reliable partners for professional power toolusers.
Technical Data
DCS332 DCS331
Voltage V
DC
14.4 18
Type 3 3
Battery type Li-Ion Li-Ion
Max. power output W 340 400
No-load speed min
-1
0–2500 0–3000
Stroke length mm 26 26
Cutting depth in:
wood mm 135 135
aluminum mm 25 25
steel mm 10 10
Bevel angle adjustment (l/r) ˚ 0–45 0–45
Weight (without battery pack) kg 2.3 2.3
Noise values and vibration values (triax vector sum) according to EN60745-2-11:
L
PA
(emission sound pressure level) dB(A) 89 89
L
WA
(sound power level) dB(A) 100 100
K (uncertainty for the given sound
level)
dB(A) 3.0 3.0
While cutting board
Vibration emission value a
h,B
= m/s
2
10.5 10.5
Uncertainty K = m/s
2
3.0 3.0
While cutting sheet metal
Vibration emission value a
h,M
= m/s
2
5.5 5.5
Uncertainty K = m/s
2
1.5 1.5
The vibration emission level given in this information sheet has
been measured in accordance with a standardised test given in
EN60745 and may be used to compare one tool with another. It
may be used for a preliminary assessment ofexposure.

WARNING: The declared vibration emission level
represents the main applications of the tool. However if
the tool is used for different applications, with different
accessories or poorly maintained, the vibration emission
may differ. This may significantly increase the exposure
level over the total workingperiod.
An estimation of the level of exposure to vibration should
also take into account the times when the tool is switched
off or when it is running but not actually doing the job.
This may significantly reduce the exposure level over the
total workingperiod.
English (original instructions)
CORDLESS JIGSAW
DCS331, DCS332

DeWalt XR Li-ION DCS331 Specifications

General

Voltage	20V
Battery Type	Li-Ion
Strokes per Minute	0-3, 000 SPM
Tool-Free Blade Change	Yes
Power Source	Battery
Variable Speed	Yes
Bevel Capacity	0-45 degrees
