Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual before use.
Wear ear protection.
Wear eye protection.
Date Code Position
The date code, which also includes the year of manufacture, is
printed into thehousing.
Example:
2016 XX XX
Year of Manufacture
Description (Fig. A, B, F, J, K)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Battery release button
2
Battery pack
3
Trigger switch
4
Trigger lock button
5
Blade release lever
6
Bevel lever
7
Shoe
8
Orbital action lever
9
Dust blower control
10
Anti-scratch shoe cover
11
Clamp Mechanism
12
Guide Roller
13
Rear Tab
14
Anti-Splinter Insert
15
Main Handle
16
Top Handle
Intended Use
Your DCS332 and DCS331 jig saws are designed for professional
cutting of wood, steel, aluminium, plastic and ceramic material
at various work sites (i.e., construction sites).
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
These heavy-duty jigsaws are professional power tools.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision. (XE requirement - English only)
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, depress the trigger lock button and
disconnect battery pack before making any
adjustments or removing/installing attachments or
accessories. An accidental start-up can cause injury.
WARNING: Use only
battery packs andchargers.
Inserting and Removing the Battery Pack
from the Tool (Fig. D)
NOTE: Make sure your battery pack
2
is fullycharged.
To Install the Battery Pack into the Tool
Handle
1. Align the battery pack
2
with the rails inside the tool’s
handle (Fig. D).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the release button
1
and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig. D)
Some
battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge button
18
. A combination of the three green LED lights will illuminate
designating the level of charge left. When the level of charge
in the battery is below the usable limit, the fuel gauge will not
illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
Blade Installation and Removal (Fig. F)
To Install a Blade
NOTE: This jig saw uses only T-shank jig saw blades.
NOTE: The DT2074 flush cutting blade is for use with D
WALT
DCS331, DCS332, DW331 and DC330 jig saws only.
NOTE: When installing flush cutting blades (DT2074), the anti-
splinter insert must be removed and the shoe must to be in the
0° positive stop position.
1. Lift the keyless blade release lever
5
as shown in figureF.
2. Insert the T-shank blade into the clamp mechanism
11
while guiding the back of the blade into the groove of the
guide rollers
12
.
3. The T-shank should be completely inside the clamp
mechanism as shown in FigureF.
