NDS3208 8 in 1 MPEG-2 Encoder User’s Manual
12 / 29
3.2.1.1 Encoder Enable
This is for user to choose to output the program or not.
3.2.1.2 Video Param
User can adjust the relevant parameters of input video in submenus of Brightness, Contrast,
Saturation and Hue. The adjustable range is 0~255, while the adjustable range of Hue is -127～
127. The figure outside the parentheses is decimal while the inside is hexadecimal.
NOTE: Below explanations are applied in this entire manual.
1) To press ENTER to start editing.
2) To move the underline through LEFT/RIGHT keys.
3) To modify the value of underlined character through UP/DOWN keys.
3.2.1.3 Encoder Param
User can modify the video, audio encoding bit rate and program information under this menu.
►3 Encoder Param
4
Output IP
Encoder Enable ON/OFF
2.1 Brightness (0~255)
128
2.2 Contrast (0~255)
128
2.3 Saturation (0~255)
128
2.3 Hue (-127~127)
000
