8514-219-001 REV E PAGE 16
SWITCHES (Pushbuttons) - continued
Description
This touch pad switch will start the operation of a dry cycle if
pressed and released once. Pressing and holding this touch pad
switch will display the current temperature of the dryer heat sensor
Start as long as it is held in the depressed position.
4-DIGIT NUMERICAL DISPLAY MESSAGES
Message Description
LOAd This message is displayed after a dry cycle is complete and the
dryer loading door has been opened or the STOP touch pad switch
on the dryer controller has been pressed and released twice.
done This message blinks immediately after completion of the dry cycle
and continues to blink until the STOP touch pad switch on the
dryer controller is pressed or the dryer loading door is opened.
Prog This message is displayed when entering the permanent
programming mode.
.15 This message appears while the dryer is in the heating time of a
dry cycle. The decimal point will blink if the output for the heating
elements is on, or remain on constantly if the output for the
heating elements is not on. The number represents the total time
left in the dry cycle (includes cool down time).
C02 This message appears when the cool down time of the dry cycle is
reached. The letter “C” represents the cool down (non-heating)
part of the dry cycle. The number(s) after the letter “C”
represent(s) the total time remaining in the dry cycle.
F5 This message appears if there is a dryer fault. The letter “F”
indicates a fault and the number after the “F” represents the
specific fault that has occurred. There are five different faults that
can appear (F1 through F5).
